The XDR-240E-48 is a 240 W DIN rail–mounted AC-DC power supply designed for industrial automation and control systems. It delivers a stable 48 V DC output with high efficiency, a slim form factor, and robust protections, making it ideal for space-saving control cabinets and demanding industrial environments.
Key Features
- Output Power: 240 W
- Output Voltage: 48 V DC
- Output Current: 5 A
- Wide Input Voltage Range: 90–264 VAC / 127–370 VDC
- High Efficiency: Typically up to 94%
- Slim DIN Rail Design: Narrow width for high-density installations
- Built-In Protections:
- Short-circuit
- Overload
- Over-voltage
- Over-temperature
- DC OK Relay Contact: Remote system monitoring
- LED Indicator: Visual confirmation of operation
- Cooling: Convection-cooled, fanless for silent operation
Technical Specifications
- Voltage Adjustment Range: Approx. 48–55 V
- Ripple & Noise: Low, suitable for sensitive industrial electronics
- Operating Temperature: –40°C to +70°C (with derating at higher temperatures)
- Dimensions: Slim-profile DIN rail housing
- Isolation: Input to output and input to ground
Applications
- Industrial automation and control systems
- Factory machinery and equipment
- PLC and SCADA systems
- Communication and networking equipment
- General-purpose 48 V DC power distribution
