Video Resolution:
1920 x 1200 x 60Hz at distances up to 50m / 150 ft.
Extension Distance:
Up to 50m / 150 ft. using CATx cable (x=5,5e,6)
Devices Supported: Supports all computers with USB style keyboards and mice, HDD15 video
connectors and audio through 3.5 mm audio jack. Supports all USB devices.
O/S Compatibility:
All known software and operating systems including Windows (all), DOS, Linux, Unix, BSD, Sun OS, Solaris, Mac OS, NetWare etc.
Connectors (local / computer):
AdderLink X50: Video input/output: HDD15, Keyboard/Mouse/ USB devices USB type B, Audio input/output: 3.5mm jack, CATx: RJ45
connector, Power: 2.5mm DC jack
AdderLink X50-MultiScreen:
Same as X50 plus extra Video input/ output: HDD15 and Serial: DB9 Connectors (remote / console): AdderLink X50: Video: HDD15, Keyboard/Mouse/USB devices: USB Type A hub, Audio: 3.5mm jack, CATx: RJ45 connector, Power: 2.5mm DC jack
AdderLink X50-MultiScreen:
Same as X50 plus extra Video: HDD15 and Serial: DB9
Physical (local / computer):
AdderLink X50: All metal case, 120mm / 4.7'' (w) x 75mm / 3''(d) x 26mm / 1'' (h) 430g / 1 lb.
AdderLink X50-MultiScreen:
All metal case, 120mm / 4.7'' (w) x 75mm / 3''(d) x 44mm / 1.7'' (h) 430g / 1 lb.
Physical (remote / console):
AdderLink X50: All metal case, 120mm / 4.7'' (w) x 75mm / 3''(d) x 26mm / 1'' (h) 430g / 1 lb.
AdderLink X50-MultiScreen:
All metal case, 120mm / 4.7'' (w) x 75mm / 3''(d) x 44mm / 1.7'' (h) 430g / 1 lb.
Power (remote only):
100 - 240VAC, 10W , 50-60Hz
Operating temperature:
0 deg C to 40 deg C / 32 deg F to 104 deg F
Approvals:
CE, FCC
