VGA pikendaja, läbi catx kuni 300m, USB ja Audio, FullHD kuni 300m, saatja+vastuvõtja

VGA pikendaja, läbi catx kuni 300m, USB ja Audio, FullHD kuni 300m, saatja+vastuvõtja

Mechanical
Height	1.02 in. (26mm)
Width	Remote - 6.4 in. (162mm) Local - 4.8 in. (122mm)
Depth	29.52 in. (75mm)
Weight	Remote- .94 lb. (430g) Local- .77 lb (350g)
Environmental
Operating Temperature	0°C to 40°C / 32°F to 104°F
Power
Power Input	100 - 240VAC 50/60Hz
Power Output	5V -12W
Supported Hardware
Connectors	4 x USB type A connectors, 1 x 15-pin high-density D type female connector (blue), 1 x 3.5mm audio jack (light green), 1 x RJ45. 1 x 2.5mm DC jack for power adapter
Audio	2 channel 16 bit Audio @ 44.1 KHz THD+N typically -80dB at 1kHz SNR typically 85dB at 1kHz
Connectors	1 x USB type B connector, 2 x 15-pin high-density D-type female connector (blue), 2 x 3.5mm audio jack (light green), 1 x RJ45. 1 x 2.5mm DC jack for optional power adapter (only required for video only applications)
Operating System Compatibility	All known software and operating systems including Windows (all), DOS, Linux, Unix, BSD, Sun OS, Solaris, Mac OS, NetWare etc
USB Devices Supported	Supports all USB 1.1 devices (full speed and low speed modes) and USB 2.0 devices that will run in low speed or full speed USB 1.1 modes
Skew Compensation	62ns de-skew with 2ns resolution (1/4 pixel at 1600x1200)
Extension Distance	200 meters using CAT5 Trunk cable 250 meters using CAT5e Trunk cable 300 meters using CAT6 Trunk cable 300 meters using CAT7 Trunk cable 200 meters using CAT7a Patch cable
Video Resolutions	All resolutions up to 1920 x 1200 @60Hz, including 1600x1200, 1080p, 1680x1050
Standards
Approved Agency	CE, FCC class A

842,77 € (ilma km-ta)

Lisa ostukorvi

Lisa soovinimekirja

Müügitingimused
Hinnad ei sisalda käibemaksu.

Manufacturer Part Number: X-USBPRO
Tootekood: EE-100-168-655

Spetsifikatsioon

Weight

0.5 kg
