Switch: 12 x GbE RJ45, 4 x 2.5 GbE Rj45, 2 x 10G SFP+, Layer 3, fanless, räkitav

16-pordiline Layer 3 Etherlighting™ switch 2.5 GbE portidega.
Overview
Dimensions
325.1 x 160 x 43.7 mm (12.8 x 6.3 x 1.7")
Port Layout
1 GbE RJ45
12
2.5 GbE RJ45
4
10G SFP+
2
Layer 3
Yes
Form Factor
Rack mount (1U), desktop, wall
Etherlighting™
Yes
Performance
Switching Capacity
84 Gbps
Total Non-Blocking Throughput
42 Gbps
Forwarding Rate
62 Mpps
Supported VLANs
1,000
MAC Address Table Size
16,000
L3 Table Size
ARP Entries
6,000
IPv4 Routes
512
Packet Buffer Size
1.5 MB
Layer 3 Features
DHCP Server (Local Networks)
Yes
DHCP Relay
Yes
Inter-VLAN Routing (Local Networks)
Yes
Static Routing (Local Networks)
Yes
Layer 2 Features
LACP Port Aggregation
Yes
STP & RSTP
Yes
QoS (DSCP)
Yes
Pro AV Profiles (Play, Dante, Q-SYS, NDI, SDVoE, Shure, AES67, Crestron)
Yes
Advanced IGMP Configuration (Querier, Fast Leave, Router Port)
Yes
IGMP Snooping
Yes
802.1X Control
Yes
MAC-Based ACLs & Device Isolation
Yes
DHCP Snooping & Guarding
Yes
Egress Rate Limit
Yes
Flow Control
Yes
Storm Control
Yes
Multicast & Broadcast Rate Limiting
Yes
MAC Address Blocking
Yes
IP-Based ACLs & Network Isolation
Yes
MAC-Based Port Restriction
Yes
Port Isolation
Yes
Port Mirroring
Yes
Jumbo Frames
Yes
250,00 € 250,00 € (ilma km-ta)

  • Number of ports
  • Number of SFP+ ports
  • Speed of switch
  • Switch type
  • Total nr of ports
 Lisa ostukorvi
Lisa soovinimekirja
Müügitingimused
Hinnad ei sisalda käibemaksu.

Manufacturer Part Number: USW-Pro-Max-16
Tootekood: EE-100-194-402

Spetsifikatsioon

Speed of switch 10 100 1000, 10 100 1000 2500, 10 100 1000 2500 5000 10000
Number of ports 16
Number of SFP+ ports 2
Switch type L3
Total nr of ports 18
