See mitmekülgne ja kompaktne switch sobib ideaalselt kaasaegsetesse ettevõttevõrkudesse. 12 GbE RJ45 porti, 4 1/2,5 GbE RJ45 porti ja 2 10G SFP+ porti tagavad 42 Gbps mittetõkestava läbilaskevõime ja 84 Gbps switching capacity, võimaldades sujuvat ühenduvust. See toetab 12 PoE/PoE+ porti ja 4 60W PoE++ porti, pakkudes 180W PoE eelarvet, et toita seadmeid nagu IP-kaamerad ja pääsupunktid. Vastupidava SGCC terasest korpusega switchil on 1,3" puutetundlik LCM-ekraan, mis lihtsustab haldamist. Layer 2 ja Layer 3 funktsioonid, nagu DHCP relay, staatiline marsruutimine ja porta isolatsioon, pakuvad tugevat võrgujuhtimist. Töökindel temperatuurivahemikus -5 kuni 40°C, see switch on sertifitseeritud CE, FCC ja IC poolt, muutes selle usaldusväärseks valikuks ettevõtte tasemel võrgustike jaoks.
| Mechanical |
|---|
| Dimensions | 325.1 x 160 x 43.7 mm (12.8 x 6.3 x 1.7") |
| Weight | 2.1 kg (4.6 lb) |
| Enclosure material | SGCC steel |
| Hardware |
|---|
| Management interface | Ethernet In-Band |
| Networking interface | (12) GbE RJ45 ports
(4) 1/2.5 GbE RJ45 ports
(2) 10G SFP+ ports |
| PoE interface | (12) PoE/PoE+ (Pins 1, 2+; 3, 6-)
(4) 60W PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 8-) |
| Total non-blocking throughput | 42 Gbps |
| Switching capacity | 84 Gbps |
| Forwarding rate | 62.496 Mpps |
| Power method | DC adapter |
| Power supply | 54V, 210W |
| Max. power consumption | 30W (Excluding PoE output) |
| Total available PoE | 180W |
| Max. PoE wattage per port by PSE | PoE: 15.4W
PoE+: 30W
PoE++: 60W |
| Voltage range PoE mode | PoE: 44—57V
PoE+/PoE++: 50—57V |
| LCM display | (1) 1.3" touchscreen |
| Button | Factory reset |
| Ambient operating temperature | -5 to 40° C (23 to 104° F) |
| Ambient operating humidity | 10 to 90% noncondensing |
| Certifications | CE, FCC, IC |
| Switching Features |
|---|
| Layer 2 features | IGMP snooping
STP / RSTP with priorities and port-level disable
Port isolation
Storm control
Voice VLAN
Port mirroring
LACP port aggregation
Multicast / broadcast rate limiting
MAC address blocking
Flow control
802.1X control
Jumbo frames
Proprietary loop protection
DHCP snooping / guarding
Egress rate limit
LLDP-MED
Port restricted by MAC
Device isolation with ACLs |
| Layer 3 features | DHCP for locally-managed networks
DHCP relay
Inter-VLAN routing between networks on same switch
Static routing between local networks
Network isolation with ACLs |
| Etherlighting™ |
|---|
| Ethernet | Locating
Speed/link
Native VLAN/network |
| SFP+ | Locating
Speed/link
Native VLAN/network |
| Application Requirements |
|---|
| UniFi Network | Version 8.1.127 and later |
