Lihtne Cloud P2P QR-koodi paigaldamine
Iseseisev 8-kanaliline UHD PoE võrguvideoregistraator
8MP (4K) samaaegne kaamera voogedastus kuni 240fps
Toetab kaheksat 4K kaamerakanalit
Toetab H.265 videokodeerimist kõrge kvaliteedi ja väikese ribalaiusega voogude jaoks
Plug and play kuni 8 TRENDnet PoE kaamerat*
Samaaegne 4K HD-video salvestamine kõigi kanalite jaoks
Üks 3,5-tolline SATA-sisene kettasahtel toetab kuni 12TB salvestusruumi (kõvaketas müüakse eraldi)
Väline USB-port toetab kuni 128 GB
Üle ühe kuu kestev 4K HD-video pidev salvestamine**
Täiustatud video taasesitus
PoE-toite eelarve: 56W
ONVIF-sertifikaat
Valmistatud Taiwanis
NDAA / TAA nõuetele vastav
Video Input
H.265 / H.264
Up to 8 cameras
Max. frame rate: 240fps
Video Output
HDMI up to 4K 3840 x 2160
VGA up to 1920 x 1080
Audio
Input: 8 Channel, G.711 u-law 8K & AAC
Output: RCA connector (0.7Vp-p, 300 – 3000Hz)
Recording
Up to 8MP resolution
H.265 / H.264
Max. network throughput: 64Mbps
8-Channel simultaneous recording up to 1080p 30fps
SATA interface for HDD or SSD up to 12TB storage each
Playback
Playback resolution: 8MP, 6MP, 5MP, 4MP, 3MP, 1080p, UXGA, 720p, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF
Hardware Standards
IEEE 802.3
IEEE 802.3u
IEEE 802.3x
IEEE 802.3ab
IEEE 802.3af
IEEE 802.3at
Device Interface
1 x Gigabit network port
8 x 100Mbps PoE ports
2 x USB 2.0 ports
1 x HDMI port
1 x VGA port
1 x SATA connector (up to 12TB)
Analog audio out port
Power port
Power switch
PoE Ports
Max. 7W per port
Power budget: 56W
Network Protocol
IPv4, UDP, TCP, ONVIF v2.2
DHCP, NTP, DDNS, SMTP, FTP, SNMP v2
HTTP, UPnP, RTSP, RTP, RTCP
Operating Temperature
0° - 40° C (32° - 104° F)
Operating Humidity
Max. 80% non-condensing
Certifications
CE
FCC
Dimensions
300 x 227 x 53mm (15 x 12 x 1.8 in.)
Weight
1kg (2.3 lb.)
Power
Input: 100 – 240V AC 50/60 Hz
Output: 48V 1.5A
Max. consumption: 6W (without camera)
Management Interface
Live view: Simultaneous 1 / 4 / 9 / 16 split
Manual, schedule (continuous, event) recording
Video export
USB external storage: firmware upgrade, import/export configuration file and logs, export recorded video files, search and playback videos directly from external storage
Local live view settings: define screen layout and channel viewing sequence
Alert messages: motion, alarm and video lost
Supported dynamic DNS services: dyndns.org and ipddns.cc
Management Setting: maximum 15 user accounts
Sentinel App
Free iOS® and Android™ apps
View live camera video
Push notifications
Take snapshots and videos
Playback
