4 x Gigabit PoE++ porti (kuni 95W)
4 x Gigabit PoE+ porti (kuni 30W)
2 x Gigabit SFP-pesa
240W PoE võimsuse eelarve
20Gbps kommutatsioonivõimsus
Sisemine toiteallikas
Ventilaatorita disain vaikse töö tagamiseks
Tugev 1U 19" rack-paigaldatav metallkorpus
|
Standards | -
IEEE 802.1p
-
IEEE 802.3
-
IEEE 802.3u
-
IEEE 802.3x
-
IEEE 802.3ab
-
IEEE 802.3af
-
IEEE 802.3at
-
IEEE 802.3bt
|
|
Device Interface | -
4 x Gigabit PoE++ ports
-
4 x Gigabit PoE+ ports
-
2 x Gigabit SFP Slots
-
LED indicators
|
|
Data Transfer Rate | -
Ethernet: 10Mbps (half duplex), 20Mbps (full duplex)
-
Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex)
-
Gigabit: 2000Mbps (full duplex)
-
Fiber: 2000Mbps (full duplex)
|
|
Performance | -
Switch Fabric: 20Gbps
-
RAM Buffer: 512KB
-
MAC Address Table: 8K entries
-
Forwarding Rate: 14.88Mpps (64-byte packet size)
-
Jumbo Frames: 9KB
|
|
Power | -
Input: 100-240V AC, 50/60Hz, internal power supply
-
Max. Consumption: 280W
|
|
PoE | -
PoE budget: 240W
-
Port 1 – 4: up to 95W
-
Port 5 – 8: up to 30W
|
|
Fan/Acoustics | |
|
MTBF | |
|
Operating Temperature | -
0° – 40° C (32° – 104° F)
|
|
Operating Humidity | |
|
Dimensions | -
330 x 230 x 44mm (13 x 9.0 x 1.7 in.)
|
|
Weight | |
|
Certifications | |
|
Warranty | |
|
PACKAGE CONTENTS |
-
TPE-BG102g
-
Quick Installation Guide
-
Rackmount kit
-
Power Cord
|
