Ambient Relative Humidity |
5% to 95%, (non-condensing) |
|
Baud Rate |
50 bps ~ 921.6 kbps, any baud rate setting |
|
Configuration |
Windows Utility, Telnet Console, Web Browser |
|
Data Bits |
5, 6, 7, 8 |
|
Dimensions |
37 x 140 x 95 mm (1.46" x 5.51" x 3.74") |
|
EMC |
CE, FCC Part 15 Subpart B (Class A) |
|
Ethernet Port |
2 with independent IP and MAC addresses |
|
Ethernet Port |
2*10/100T(X) auto negotiation speed, Full/Half duplex mode, and auto MDI/MDI-X connection |
|
Flow Control |
XON/XOFF, RTS/CTS |
|
Green |
RoHS Compliant |
|
Hazardous Location |
UL/cUL (Class 1, Division 2, Groups A, B, C and D) |
|
Housing |
Metal with solid mounting hardware |
|
Input Voltage |
12 to 48VDC, Redundant Inputs |
|
LED Indicators |
Link / Act |
|
LED Indicators |
System: Power, System Status
LAN: Speed, Link/Active
Serial: Tx, Rx |
|
Mounting |
DIN-Rail Mounting, Wall Mounting |
|
Operating Temperature |
-40° ~ 70°C |
|
Operation Mode |
Modbus RTU Master/Slave mode
Modbus ASCII Master/Slave mode |
|
OS Support |
32-bit/64-bit Windows XP/Vista/7/8/8.1/10, Windows Server 2003/2008/2008 R2/2012/2012 R2 |
|
Overload Current Protection |
Present |
|
Parity |
None, Odd, Even, Space, Mark |
|
Port Type |
RS-232/422/485, software selectable |
|
Power Connection |
Terminal block |
|
Power Consumption |
3.2 W |
|
Processing Type |
Store and Forward |
|
Protection |
15 KV ESD for all signals |
|
Protocols |
CSMA/CD |
|
Protocols |
ICMP, IP, TCP, UDP, BOOTP, DHCP, Auto IP, SNMP, HTTP, DNS, SMTP, ARP, NTP |
|
Reboot Trigger |
Built-in WDT (watchdog timer) |
|
Reverse Polarity Protection |
Present |
|
Serial Port |
2 - DB9 male |
|
Serial Signals |
RS-232: TxD, RxD, CTS, RTS, DCD, RI, GND
RS-422: TxD+, TxD-, RxD+, RxD-, GND
RS-485: Data+, Data-, GND |
|
Standards |
IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX Fast Ethernet |
|
Stop Bits |
1, 2 |
|
Storage Temperature |
-40° ~ 85°C |
|
Utility Software |
Antaira Device Configuration Utility |
|
Warranty |
5 Years |
|
Weight |
1.06 lbs (0.48 kg) |
