Pooljuhtrelee (SSR) 25A/400VAC/Juhtimispinge 8-32V/450A²S/Juhuslik

Pooljuhtrelee (SSR) 25A/400VAC/Juhtimispinge 8-32V/450A²S/Juhuslik

Kogege mitmekülgset ja täpset vahelduvvoolu kontrolli meie AC juhusliku väljundmooduliga. Selle 25A türistori reiting ja maksimaalne lülitusvool 25A tagavad suurepärase jõudluse. Sobib mitmesugusteks rakendusteks alates kütteelementidest kuni elektromagnetklappide ja kontaktoriteni. Lihtne paigaldada trükkplaatidele, see töötab vahelduvpinge vahemikus 24-600VAC ja juhtimispinge vahemikus 8-32VDC. Vastavuses CE, EAC, UKCA ja UL standarditega, see tagab tipptasemel kvaliteedi ja ohutuse teie elektrivajadustele.
Specifications:
Thyristor rating: 25A
Max. switching current (A): 25A
Type of mounting: PCB
Number of poles: 1 - Single phase
Function: AC on/off Random
Switching voltage rate: 24-600VAC
Control voltage rate: 8-32VDC

Standards:
Compliant with CE, EAC, UKCA, and UL (cURus)

Features:
SSR 25A/24-600VAC/CTRL 8-32VDC/450A²S/RANDOM
Type of relay: AC
Series: SK
Heatsink included: NO
Terminals (power): "PCB" pins
Housing type: PCB relay

Application:
(AC-1 / LC A) Heating elements
(AC-3 / LC B) Motors
(AC-5a / LC C) Discharge lamps
(AC-5a / LC D) Incandescent light bulbs and infrared lamps
(AC-5b/DC-6) LEDs
(AC-6a / LC E) Transformers
(AC-6b / LC F) Capacitors
(AC-14/AC-15/DC-13) Electrovalves and electromagnets
(AC-14/AC-15/DC-13/DC-14) Contactors
71,54 € 71,54 € (ilma km-ta)

  • Min thyristor rating per phase (A)
  • Relay application
  • Relay control voltage nominal
  • Relay enclosure
  • Relay function
  • Relay heatsink
  • Relay max switching current per phase 40c a
  • Relay number of poles
  • Relay standards
  • Relay switching voltage
  • Relay terminals
  • Relay type AC DC
  • Relay type of mounting
  • Weight
 Lisa ostukorvi
Lisa soovinimekirja
Müügitingimused
Hinnad ei sisalda käibemaksu.
Dokumendid
CC_Mono TOR.pdf FT_SKL20241.pdf

Manufacturer Part Number: SKL20241
Tootekood: EE-100-188-122

Spetsifikatsioon

Relay application Ac 14 ac 15 dc 13 cc 14 contactors, Ac 14 ac 15 dc 13 electrovalves and electromagnets, Ac 3 lc b motors, Ac 5a lc c discharge lamps, Ac 5a lc d incandescent light bulbs and infrared lamps, Ac 5b dc 6 leds, Ac 6a lc e transformers, Ac 6b lc f capacitors, Ac1 lca heating elements
Relay control voltage nominal 24 VDC, 5/12/24 VDC
Relay standards CE, EAC, UKCA, UL cURus
Relay switching voltage 110/120 VAC, 230 VAC, 400 VAC, 480 VAC, 600 VAC
Min thyristor rating per phase (A) 20 29 (Min thyristor rating per phase (A))
Relay enclosure Pcb relay
Relay function Ac on off random
Relay heatsink No (Relay heatsink)
Relay max switching current per phase 40c a 20 29 (Relay max switching current per phase 40c a)
Relay number of poles Single phase
Relay terminals Pcb pins
Relay type AC DC AC
Relay type of mounting Pcb (Relay type of mounting)
Weight 0.0126 kg
