Pooljuhtrelee (SSR) 25A/690VAC/Juhtimispinge 4-14V/1150A²S

Pooljuhtrelee (SSR) 25A/690VAC/Juhtimispinge 4-14V/1150A²S

Kogege täpset ja usaldusväärset juhtimist meie AC null-ristumise väljundmooduliga. Sellel on tugev 22A türistori hinnang ja maksimaalne lülitusvool 22A, mis tagab tõhusa jõudluse laias valikus rakendustes. Ideaalne kütteelementide, mootorite, lampide, LED-ide, transformaatorite ja kondensaatorite juhtimiseks, see töötab sujuvalt lülituspingega vahemikus 24-690VAC ja juhtimispingega vahemikus 4-14VDC. Vastavuses CE, EAC ja UKCA standarditega tagab tipptasemel kvaliteedi ja ohutuse kõigi teie elektrivajaduste jaoks.
Specifications
Type: AC Zero cross output
Thyristor Rating: 22A
Max. Switching Current (A): 22A
Type of Mounting: PCB
Number of Poles: 1- Single phase
Function: AC on/off Zero-Cross
Switching Voltage Rate: 24-690VAC
Control Voltage Rate: 4-14VDC

Standards:
CE
EAC
UKCA

Features
SSR: 25A/24-690VAC/CTRL 4-14VDC/1150A²S
Type of Relay (AC or DC): AC
Series: SK
Heatsink Included: NO
Terminals (Power): “PCB” pins
Housing Type: PCB relay

Application:
(AC-1 / LC A) Heating elements
(AC-3 / LC B) Motors
(AC-5a / LC C) Discharge lamps
(AC-5a / LC D) Incandescent light bulbs and infrared lamps
(AC-5b/DC-6) LEDs
(AC-6a / LC E) Transformers
(AC-6b / LC F) Capacitors
(AC-14/AC-15/DC-13) Electrovalves and electromagnets
(AC-14/AC-15/DC-13/DC-14) Contactors
75,66 € 75,66 € (ilma km-ta)

  • Min thyristor rating per phase (A)
  • Relay application
  • Relay control voltage nominal
  • Relay enclosure
  • Relay function
  • Relay heatsink
  • Relay max switching current per phase 40c a
  • Relay number of poles
  • Relay standards
  • Relay switching voltage
  • Relay terminals
  • Relay type AC DC
  • Relay type of mounting
  • Weight
 Lisa ostukorvi
Lisa soovinimekirja
Müügitingimused
Hinnad ei sisalda käibemaksu.
Dokumendid
CC_Mono TOR.pdf FT_SKL10260.pdf

Manufacturer Part Number: SKL10260
Tootekood: EE-100-188-115

Spetsifikatsioon

Relay application Ac 14 ac 15 dc 13 cc 14 contactors, Ac 14 ac 15 dc 13 electrovalves and electromagnets, Ac 3 lc b motors, Ac 5a lc c discharge lamps, Ac 5a lc d incandescent light bulbs and infrared lamps, Ac 5b dc 6 leds, Ac 6a lc e transformers, Ac 6b lc f capacitors, Ac1 lca heating elements
Relay standards CE, EAC, UKCA
Relay switching voltage 110/120 VAC, 230 VAC, 400 VAC, 480 VAC, 600 VAC
Min thyristor rating per phase (A) 20 29 (Min thyristor rating per phase (A))
Relay control voltage nominal 5/12/24 VDC
Relay enclosure Pcb relay
Relay function Ac on off zero crossing
Relay heatsink No (Relay heatsink)
Relay max switching current per phase 40c a 20 29 (Relay max switching current per phase 40c a)
Relay number of poles Single phase
Relay terminals Pcb pins
Relay type AC DC AC
Relay type of mounting Pcb (Relay type of mounting)
Weight 0.0126 kg
