Pooljuhtrelee (SSR) 3A/60VDC/Juhtimispinge 3-30V

Pooljuhtrelee (SSR) 3A/60VDC/Juhtimispinge 3-30V

Kogege tõhusat juhtimist meie Bipolaarse transistori alalisvoolu väljundmooduliga. Koos 3A türistori hinnangu ja maksimaalse lülitusvooluga 3A pakub see moodul usaldusväärset jõudlust mitmesugustes alalisvoolu rakendustes. See töötab sujuvalt lülituspinge vahemikus 2-60VDC ja juhtimispinge vahemikus 3-30VDC. Konstrueeritud lihtsaks paigaldamiseks trükkplaadile, vastab see CE ja UKCA standarditele, tagades kvaliteedi ja ohutuse. Ideaalne valik LED-valgustite, lampide, elektromagnetite ja muude juhtimisrakenduste jaoks.
Specifications:
Bipolar transistor DC output
Thyristor rating: 3A
Max. switching current: 3A
Type of mounting: PCB
Number of poles: 1 (Single phase)
Function: DC on/off
Switching voltage rate: 2-60VDC
Control voltage rate: 3-30VDC

Standards:
CE
UKCA

Features:
SSR 3A/2-60VDC/CTRL 3-30VDC
Type of relay: DC
Series: SK
Heatsink included: NO
DC Technology: BIPOLAR
Terminals (power): “PCB” pins
Housing type: PCB relay

Application:
(AC-5a / LC D) Incandescent light bulbs and infrared lamps
(AC-5b/DC-6) LEDs
(AC-14/AC-15/DC-13) Electrovalves and electromagnets
(AC-14/AC-15/DC-13/DC-14) Contactors
PLC Inputs/Outputs
34,10 € 34,10 € (ilma km-ta)

  • Min thyristor rating per phase (A)
  • Relay application
  • Relay control voltage nominal
  • Relay enclosure
  • Relay function
  • Relay heatsink
  • Relay max switching current per phase 40c a
  • Relay number of poles
  • Relay output protection type
  • Relay standards
  • Relay switching voltage
  • Relay terminals
  • Relay type AC DC
  • Relay type of mounting
  • Weight
 Lisa ostukorvi
Lisa soovinimekirja
Müügitingimused
Hinnad ei sisalda käibemaksu.
Dokumendid
CC_DC.pdf FT_SKD10306.pdf

Manufacturer Part Number: SKD10306
Tootekood: EE-100-188-106

Spetsifikatsioon

Relay application Ac 14 ac 15 dc 13 cc 14 contactors, Ac 14 ac 15 dc 13 electrovalves and electromagnets, Ac 5a lc d incandescent light bulbs and infrared lamps, Ac 5b dc 6 leds, Plc inputs outputs
Relay control voltage nominal 24 VDC, 5/12/24 VDC
Relay standards CE, Ukca (Relay standards)
Min thyristor rating per phase (A) 3
Relay enclosure Pcb relay
Relay function Dc on off
Relay heatsink No (Relay heatsink)
Relay max switching current per phase 40c a 3
Relay number of poles Single phase
Relay output protection type Reverse diode
Relay switching voltage 0–110 VDC
Relay terminals Pcb pins
Relay type AC DC DC
Relay type of mounting Pcb (Relay type of mounting)
Weight 0.0205 kg
