Pooljuhtrelee (SSR) 5A/400VAC/Juhtimispinge 3-10V/LED

Pooljuhtrelee (SSR) 5A/400VAC/Juhtimispinge 3-10V/LED

Kogege täpset ja tõhusat juhtimist meie SKA11440 AC null-ristumise väljundmooduliga, millel on väljundkaitse täiustatud ohutuse tagamiseks. Robustse 5A türistori hinnangu ja maksimaalse lülitusvooluga 5A tagab see moodul usaldusväärse toimimise laias vahemikus lülituspinge 12-460VAC ja juhtimispinge 3-10VDC juures. Varustatud LED-indikaatoritega, sobib see ideaalselt kütteelementide, mootorite, lampide, LED-ide ja muu juhtimiseks. Vastavalt CE, UKCA ja UL standarditele on see mitmesugusteks elektrirakendusteks ideaalne lahendus.
Specifications:
AC Zero cross output - with output protection
Thyristor rating: 5A
Max. switching current: 5A
Type of mounting: PCB
Number of poles: 1 - Single phase
Function: AC on/off Zero-Cross
Switching voltage rate: 12-460VAC
Control voltage rate: 3-10VDC

Standards:
CE
UKCA
UL (cURus)

Features:
SSR 5A/12-460VAC/CTRL 3-10V/LED
Type of relay: AC
Series: SK
Output protection Type: VDR
Heatsink included: NO
Terminals (power): "PCB" pins
Housing type: PCB relay

Application:
(AC-1 / LC A) Heating elements
(AC-3 / LC B) Motors
(AC-5a / LC C) Discharge lamps
(AC-5a / LC D) Incandescent light bulbs and infrared lamps
(AC-5b/DC-6) LEDs
(AC-14/AC-15/DC-13) Electrovalves and electromagnets
(AC-14/AC-15/DC-13/DC-14) Contactors
PLC Inputs/Outputs
59,97 € 59,97 € (ilma km-ta)

  • Min thyristor rating per phase (A)
  • Relay application
  • Relay control voltage nominal
  • Relay enclosure
  • Relay function
  • Relay heatsink
  • Relay max switching current per phase 40c a
  • Relay number of poles
  • Relay output protection type
  • Relay standards
  • Relay switching voltage
  • Relay terminals
  • Relay type AC DC
  • Relay type of mounting
  • Weight
 Lisa ostukorvi
Lisa soovinimekirja
Müügitingimused
Hinnad ei sisalda käibemaksu.
Dokumendid
CC_Mono TOR.pdf FT_SKA11440.pdf

Manufacturer Part Number: SKA11440
Tootekood: EE-100-188-095

Spetsifikatsioon

Relay application Ac 14 ac 15 dc 13 cc 14 contactors, Ac 14 ac 15 dc 13 electrovalves and electromagnets, Ac 3 lc b motors, Ac 5a lc c discharge lamps, Ac 5a lc d incandescent light bulbs and infrared lamps, Ac 5b dc 6 leds, Ac1 lca heating elements, Plc inputs outputs
Relay standards CE, UKCA, Ul curus (Relay standards)
Relay switching voltage 110/120 VAC, 230 VAC, 400 VAC
Min thyristor rating per phase (A) 5
Relay control voltage nominal 5/12/24 VDC
Relay enclosure Pcb relay
Relay function Ac on off zero crossing
Relay heatsink No (Relay heatsink)
Relay max switching current per phase 40c a 5
Relay number of poles Single phase
Relay output protection type VDR
Relay terminals Pcb pins
Relay type AC DC AC
Relay type of mounting Pcb (Relay type of mounting)
Weight 0.0194 kg
