Reverser I=16AC3/24-550VAC/CD12-30VDC

Reverser I=16AC3/24-550VAC/CD12-30VDC

Kogege täpset juhtimist ja usaldusväärset toimimist meie SGR8671510 AC mootori reverseriga. Tõhususeks loodud releel on tugev 3x60A türistori reiting, mis tagab sujuva töö pingeväärtuste vahemikus 24-520VAC. Ideaalne mitmesuguste mootori juhtimise rakenduste jaoks, see vastab CE, EAC, UKCA ja UL standarditele, tagades usaldusväärse toimimise tööstuskeskkondades.
Specifications:
Type: AC Motor Reverser Control - 2-phase switching - with output protection
Thyristor Rating: 3x60A
Max. Switching Current (A): 3x16A AC-3 @40°C
Type of Mounting: To screw
Number of Poles: 3 - Three-phase
Function: Inverter
Switching Voltage Rate: 24-520VAC
Control Voltage Rate: 12-30VDC

Standards:
CE
EAC
UKCA
UL (cURus)

Features:
Model: Motor Reverser TRI 3X5AC53/24-520V/CTRL 12-30VDC
Type of Relay: AC
Series: SGR
Output Protection Type: RC, VDR
Heatsink Included: NO
Terminals (Power): Screws
Housing Type: Standard

Application:
(AC-3 / LC B) Motors
412,73 € 412,73 € (ilma km-ta)

  • Min thyristor rating per phase (A)
  • Relay application
  • Relay control voltage nominal
  • Relay enclosure
  • Relay function
  • Relay heatsink
  • Relay max switching current per phase 40c a
  • Relay number of poles
  • Relay output protection type
  • Relay standards
  • Relay switching voltage
  • Relay terminals
  • Relay type AC DC
  • Relay type of mounting
  • Weight
 Lisa ostukorvi
Lisa soovinimekirja
Müügitingimused
Hinnad ei sisalda käibemaksu.
Dokumendid
FT_SGR8671510.pdf IS_SG.pdf

Manufacturer Part Number: SGR8671510
Tootekood: EE-100-188-014

Spetsifikatsioon

Relay control voltage nominal 24 VDC, 5/12/24 VDC
Relay output protection type Rc, VDR
Relay standards CE, EAC, UKCA, UL cURus
Relay switching voltage 110/120 VAC, 230 VAC, 400 VAC, 480 VAC
Min thyristor rating per phase (A) 60 69 (Min thyristor rating per phase (A))
Relay application Ac 3 lc b motors
Relay enclosure Standard (Relay enclosure)
Relay function Inverter
Relay heatsink No (Relay heatsink)
Relay max switching current per phase 40c a 10 19 (Relay max switching current per phase 40c a)
Relay number of poles Three phase
Relay terminals Screws
Relay type AC DC AC
Relay type of mounting Screw (Relay type of mounting)
Weight 0.2702 kg
