Toiteplokk DIN-liistule 480W 48V 10A

Technical data		Information
Brand	Mean Well	Commodity	8504409090
Item number	SDR-480-48	Warranty pack	36 Months Bring-In
Series	SDR-480	RoHS	Compliant
Description	AC-DC Industrial DIN rail power supply; Output 48Vdc at 10A; Metal casing; Ultra slim width 85.5mm	Packing quantity	8
Application	Installation UL 508 ITE EN/UL/IEC 60950	Net weight (gram)	1820
Technology	AC/DC
Power Format	DIN rail
Output Power (W)	480
Output Voltage (V)	48
Output Current (A)	10
Input Voltage (V)	90 - 264 Universal Input 110/230V
IP Rating	No IP assigned
Width (mm)	85.5
Height (mm)	125.2
Depth (mm)	128.5
Control Signals	DC OK
Dimming Technology	No Dimming

127,80 € (ilma km-ta)

Müügitingimused
Hinnad ei sisalda käibemaksu.

Dokumendid

SDR-480-spec.pdf

Manufacturer Part Number: SDR-480-48
Tootekood: EE-100-184-926

Weight

1.1 kg
