Pooljuhtrelee (SSR) 30A - 200 VDC - Juhtimispinge 4,5-32VDC

Pooljuhtrelee (SSR) 30A - 200 VDC - Juhtimispinge 4,5-32VDC

SCM030200 suure võimsusega alalisvoolu väljundmoodul pakub usaldusväärset lahendust väga erinevate alalisvoolu koormuste lülitamiseks kuni 30A vooluni. See mitmekülgne moodul kasutab MOSFET-tehnoloogiat tõhusaks alalisvoolu lülitamiseks, laia juhtimispinge vahemikuga ja turvaliste kruvikeermetega klemmidega. Ideaalne aku pankade, alalisvoolu mootori juhtimise, tööstusautomatiseerimise, LED-valgustuse juhtimise ja muu jaoks. (Jahutusradiaator vajalik, müüakse eraldi)
Specifications:
Thyristor Rating: 30A (MOSFET Technology)
Max. Switching Current (A): 30A (de-rating required for continuous operation)
Type of Mounting: Screw mount
Number of Poles: 1 (Single phase)
Function: DC On/Off
Switching Voltage Rate: 2-200VDC
Control Voltage Rate: 4.5-32VDC

Standards: CE, EAC, UKCA, UL (cULus)

Features:
DC Output: 30A / 2-200VDC (MOSFET)
Wide Control Voltage: 4.5-32VDC
Suitable for Various DC Loads:
Heating elements (AC-1 / LC A)
Incandescent light bulbs and infrared lamps (AC-5a / LC D)
LEDs (AC-5b/DC-6)
Electrovalves and electromagnets (AC-14/AC-15/DC-13)
Contactors (AC-14/AC-15/DC-13/DC-14)
Series: SCM
Heatsink: Not Included (Required for most applications)
Terminals (Power): Screws
Housing Type: Hockey Puck

Applications:
Battery Banks and Distribution
DC Motor Control (Brushed and Brushless)
Industrial Automation Systems
LED Lighting Control
321,55 € 321,55 € (ilma km-ta)

  • Min thyristor rating per phase (A)
  • Relay application
  • Relay control voltage nominal
  • Relay enclosure
  • Relay function
  • Relay heatsink
  • Relay max switching current per phase 40c a
  • Relay number of poles
  • Relay output protection type
  • Relay standards
  • Relay switching voltage
  • Relay terminals
  • Relay type AC DC
  • Relay type of mounting
  • Weight
 Lisa ostukorvi
Lisa soovinimekirja
Müügitingimused
Hinnad ei sisalda käibemaksu.
Dokumendid
CC_DC.pdf FA_SCM030200.pdf

Manufacturer Part Number: SCM030200
Tootekood: EE-100-187-911

Spetsifikatsioon

Relay application Ac 14 ac 15 dc 13 cc 14 contactors, Ac 14 ac 15 dc 13 electrovalves and electromagnets, Ac 5a lc d incandescent light bulbs and infrared lamps, Ac 5b dc 6 leds, Ac1 lca heating elements
Relay control voltage nominal 24 VDC, 5/12/24 VDC
Relay standards CE, EAC, UKCA, UL cURus
Min thyristor rating per phase (A) 30 39 (Min thyristor rating per phase (A))
Relay enclosure Hockey puck
Relay function Dc on off
Relay heatsink No (Relay heatsink)
Relay max switching current per phase 40c a 30 39 (Relay max switching current per phase 40c a)
Relay number of poles Single phase
Relay output protection type Reverse diode
Relay switching voltage 110 VDC
Relay terminals Screws
Relay type AC DC DC
Relay type of mounting Screw (Relay type of mounting)
Weight 0.1107 kg
