Pooljuhtrelee (SSR) 150A/100VDC/Juhtimispinge 4,5-32VDC

Pooljuhtrelee (SSR) 150A/100VDC/Juhtimispinge 4,5-32VDC

SCM0150100 alalisvoolu väljundmoodul pakub jõulist lahendust nõudlike alalisvoolu koormuste lülitamiseks kuni tohutute 150A-ni. See vastupidav moodul kasutab MOSFET-tehnoloogiat tõhusaks alalisvoolu lülitamiseks ja pakub laia juhtimispinge vahemiku lihtsaks integreerimiseks. Ideaalne suure voolutugevusega aku süsteemidele ja tööstuslike mootorite juhtimiseks. (Jahutusradiaator vajalik, müüakse eraldi)
Specifications:
Thyristor Rating: 150A (MOSFET Technology)
Max. Switching Current (A): 150A (de-rating required for continuous operation)
Type of Mounting: Screw mount
Number of Poles: 1 (Single phase)
Function: DC On/Off
Switching Voltage Rate: 2-100VDC
Control Voltage Rate: 4.5-32VDC

Standards: CE, EAC, UKCA, UL (cULus)

Features:
Ultra High Power DC Output: 150A / 2-100VDC (MOSFET)
Wide Control Voltage: 4.5-32VDC
Suitable for Various DC Loads:
Heating elements (AC-1 / LC A)
Incandescent light bulbs and infrared lamps (AC-5a / LC D) (Derating may apply)
LEDs (AC-5b/DC-6) (Derating may apply)
Electrovalves and electromagnets (AC-14/AC-15/DC-13)
Contactors (AC-14/AC-15/DC-13/DC-14)
Series: SCM
Heatsink: Required (Sold Separately) - Due to the high power rating, a properly sized heatsink is crucial for safe operation.
Terminals (Power): Screws
Housing Type: Hockey Puck

Applications:
High Current Battery Bank Switching and Distribution
Industrial DC Motor Control (Brushed and Brushless) - Consult a qualified engineer for specific motor applications.
Large Scale Electrolysis Control (e.g., Hydrogen Production)
Heavy-Duty Industrial Automation Systems
441,21 € 441,21 € (ilma km-ta)

  • Min thyristor rating per phase (A)
  • Relay application
  • Relay control voltage nominal
  • Relay enclosure
  • Relay function
  • Relay heatsink
  • Relay max switching current per phase 40c a
  • Relay number of poles
  • Relay output protection type
  • Relay standards
  • Relay switching voltage
  • Relay terminals
  • Relay type AC DC
  • Relay type of mounting
  • Weight
 Lisa ostukorvi
Lisa soovinimekirja
Müügitingimused
Hinnad ei sisalda käibemaksu.
Dokumendid
CC_DC.pdf FA_SCM0150100.pdf

Manufacturer Part Number: SCM0150100
Tootekood: EE-100-187-910

Spetsifikatsioon

Relay application Ac 14 ac 15 dc 13 cc 14 contactors, Ac 14 ac 15 dc 13 electrovalves and electromagnets, Ac 5a lc d incandescent light bulbs and infrared lamps, Ac 5b dc 6 leds, Ac1 lca heating elements
Relay control voltage nominal 24 VDC, 5/12/24 VDC
Relay standards CE, EAC, UKCA, UL cURus
Min thyristor rating per phase (A) 100 150 (Min thyristor rating per phase (A))
Relay enclosure Hockey puck
Relay function Dc on off
Relay heatsink No (Relay heatsink)
Relay max switching current per phase 40c a 100 150 (Relay max switching current per phase 40c a)
Relay number of poles Single phase
Relay output protection type Reverse diode
Relay switching voltage 0–110 VDC
Relay terminals Screws
Relay type AC DC DC
Relay type of mounting Screw (Relay type of mounting)
Weight 0.1163 kg
