Pooljuhtrelee (SSR) 15 A - 60 VDC - Juhtimispinge 10-32 VDC

Pooljuhtrelee (SSR) 15 A - 60 VDC - Juhtimispinge 10-32 VDC

SCC21506 suure vooluga bipolaarse transistori alalisvoolu väljundmoodul pakub võimsat lahendust kuni 15A vooluga alalisvoolu koormuste lülitamiseks. See vastupidav moodul kasutab bipolaartehnoloogiat tõhusaks alalisvoolu juhtimiseks ja tal on lai pingevahemik. Ideaalne aku süsteemidele, tööstusautomatiseerimisele, robootikale, päikeseenergeetika süsteemidele ja muule. (Jahutusradiaator vajalik, müüakse eraldi)
Specifications:
Thyristor Rating: Equivalent to 15A (Bipolar Transistor Technology)
Max. Switching Current (A): 15A (de-rating required for continuous operation)
Type of Mounting: Screw mount
Number of Poles: 1 (Single phase)
Function: DC On/Off
Switching Voltage Rate: 2-60VDC (Wide DC Range)
Control Voltage Rate: 10-32VDC

Standards: CE, EAC, UKCA

Features:
High Current DC Output: 15A / 2-60VDC (BJT Technology)
Wide Control Voltage: 10-32VDC
Screw Terminals for Secure Connections
Suitable for Various DC Loads (de-rating may apply):
Electrovalves and Solenoids (AC-14, AC-15, DC-13)
Contactors (AC-14, AC-15, DC-13, DC-14)
Series: SCC
Heatsink: Required (Sold Separately) - A properly sized heatsink is crucial for safe operation, especially at higher loads or ambient temperatures.
Housing Type: Hockey Puck

Applications:
Battery Bank Control and Management (Charging/Discharging)
Industrial Automation Systems (High Current DC Control)
Robotics and Machine Control (DC Motors, Solenoids)
Solar Power System Control (Battery Charging)
LED Driver Applications (High Current)
165,76 € 165,76 € (ilma km-ta)

  • Min thyristor rating per phase (A)
  • Relay application
  • Relay control voltage nominal
  • Relay enclosure
  • Relay function
  • Relay heatsink
  • Relay max switching current per phase 40c a
  • Relay number of poles
  • Relay output protection type
  • Relay standards
  • Relay switching voltage
  • Relay terminals
  • Relay type AC DC
  • Relay type of mounting
  • Weight
 Lisa ostukorvi
Lisa soovinimekirja
Müügitingimused
Hinnad ei sisalda käibemaksu.
Dokumendid
CC_DC.pdf FT_SCCP6.pdf

Manufacturer Part Number: SCC21506
Tootekood: EE-100-187-899

Spetsifikatsioon

Relay application Ac 14 ac 15 dc 13 cc 14 contactors, Ac 14 ac 15 dc 13 electrovalves and electromagnets
Relay control voltage nominal 24 VDC, 5/12/24 VDC
Relay standards CE, EAC, UKCA
Min thyristor rating per phase (A) 10 19 (Min thyristor rating per phase (A))
Relay enclosure Hockey puck
Relay function Dc on off
Relay heatsink No (Relay heatsink)
Relay max switching current per phase 40c a 10 19 (Relay max switching current per phase 40c a)
Relay number of poles Single phase
Relay output protection type Reverse diode
Relay switching voltage 0–110 VDC
Relay terminals Screws
Relay type AC DC DC
Relay type of mounting Screw (Relay type of mounting)
Weight 0.0963 kg
