SC841910 väiksema vooluga ühefaasiline vahelduvvoolu väljundmoodul nullpunktilülitimise ja väljundkaitsega (12A) pakub kompaktset lahendust väga väikeste vooludega vahelduvvoolu koormuste juhtimiseks madalama pingevahemikuga (12-280VAC). See moodul on varustatud integreeritud ülepingekaitsega ja unikaalse suure vahemikuga juhtimispingega (90-240VAC). Ideaalne tööstusautomatiseerimiseks, hoonete automatiseerimiseks ja muuks. (Jahutusradiaator vajalik, müüakse eraldi)
Specifications:
Thyristor Rating: Equivalent to 12A (SSR Technology)
Max. Switching Current (A): 12A (de-rating required for continuous operation)
Type of Mounting: Screw mount
Number of Poles: 1 (Single phase)
Function: AC On/Off (Zero-Cross)
Switching Voltage Rate: 12-280VAC (Lower AC Range)
Control Voltage Rate: 90-240VAC (Higher Control Voltage Range)
Standards: CE, EAC, UKCA, UL (cULus), VDE
Features:
Ultra-Low Current AC Output: 12A / 12-280VAC (SSR Technology) - Ideal for very low power applications
Lower AC Switching Voltage Range: 12-280VAC
Higher Control Voltage Range: 90-240VAC - More flexible control system compatibility
Screw Terminals for Secure Connections
Zero-Cross Switching - Reduces Electrical Noise and Transients
Integrated RC Snubber Circuit - Provides Output Surge Protection
Suitable for Various AC Loads (de-rating may apply):
Heating Elements (AC-1 / LC A) - Lower Power
Discharge Lamps (AC-5a / LC C) - Lower Power
Incandescent Bulbs and Infrared Lamps (AC-5a / LC D) - Lower Power
LEDs (AC-5b/DC-6)
Capacitors (AC-6b / LC F) Use with Caution and Consult a Qualified Engineer
Electrovalves and Solenoids (AC-14/AC-15/DC-13)
Contactors (AC-14/AC-15/DC-13/DC-14) - Lower Power
Series: SC8
Heatsink: Required (Sold Separately) - A properly sized heatsink is crucial for safe operation, especially at higher loads or ambient temperatures.
Housing Type: Hockey Puck
Applications:
Industrial Automation Systems (Ultra-Low Current AC Loads with Lower Voltage Requirements)
Building Automation Systems (Low Power Control Applications)
Machine Control (Very Low Power Solenoid Activation)
Instrumentation and Sensor Power Control (Compatible with Higher Control Voltages)
Security Systems (Powering Low Current Devices within Voltage Range)
