Dino-Lite WF4115ZTL on juhtmevaba mudel, mis kuulub pika tööulatusega (LWD) seeria hulka. Vahetage hetkega juhtmevaba ja juhtmega ühenduse vahel. Töötage juhtmega USB kaudu või juhtmevabalt kaasasoleva WF-20 adapteriga. WF4115ZTL on varustatud tipptasemel funktsioonidega nagu paindlik LED-juhtimine (FLC), integreeritud polarisaator ja ulatuslikud mõõtmise võimalused.
WF4115ZTL peamised omadused on:
Täielikult juhtmevaba lahendus (kaasa arvatud WF20)
1,3 megapiksline Edge sensor
Suurendus 10-140x
Pikk tööulatus (LWD)
Reguleeritav polarisaator
Paindlik LED-juhtimine (FLC)
Ja palju muud...
(EDOF/EDR töötab ainult Windows OS-is)
Lighting
Light/ LED typeWhite
Number of LEDs8
LED on/off switchable:Yes
Infrared filterIR cut-filter >650 nm
Diffuser availableYes (N3C-D included)
Emission filterNo
PolarizerYes, linear
Optics
Magnification10-140x
Macro zoomNo
Working distanceLong
Lens typeGlass with anti-reflection coating
Sensor
Sensor typeCMOS
Resolution1.3 Megapixel (1280x1024)
Maximum frame rate30 fps
Compatibility
InterfaceUSB 2.0
Operating systemWindows 7, 8, 10 & 11, MacOS 10.11.6 and up
SoftwareDinoCapture 2.0 (Windows), DinoXcope (Mac OS)
Supported image formats (Windows)BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA, PCX, MNG, WBMP, JP2, JPC, PGX
Supported video formats (Windows)WMV, FLV, SWF
Supported image formats (MacOS)JPEG, PNG
Supported video formats (MacOS)MOV
Imaging standardsDirectShow, UVC
WifiYes
Housing
Housing materialComposite/ plastic housing
Magnification lockYes
Dimensions11.4cm (L) x 3.3cm (D)
Weight111g
Cable length1.8m
Features
Special featureFlexible LED Control (FLC)
MeasurementYes
CalibrationYes
Microtouch sensorYes
ESD safeNo
Information
Package contentsMicroscope, WF-20, carry pouch, calibration target, user manual, N3C-O- Open cap, N3C-C- Closed cap, N3C-D- diffuser cap, N3C-extension cap, N3C-L- Long cap, N3C-S- Side light cap
Warranty information2 years European warranty
Regulatory approvalCE, FCC, ROHS
