Dino-Lite EarScope Basic Wireless (MEDLW3E) on kompaktne ja ohutu lahend kõrva uurimiseks. Hügieenilistel põhjustel on kork eemaldatav. MEDLW3E eraldusvõime on 640x480 pikslit ja suurendus 20-30x. See mudel tarnitakse koos 3, 4 ja 5 mm suuruste ühekordsete spekulumidega (10 tk iga suuruse kohta).
Lighting
Light/ LED typeWhite
Number of LEDs4
LED on/off switchable:Yes
Infrared filterIR cut-filter >650 nm
Diffuser availableNo
PolarizerNo
Optics
Magnification20-30x
Lens typeGlass with anti-reflection coating
Sensor
Sensor typeCMOS
ResolutionVGA (640x480)
Maximum frame rate30 fps
Compatibility
InterfaceUSB 2.0
Operating systemWindows 7, 8, 10 & 11, MacOS 10.9 and up
SoftwareDinoCapture 2.0 (Windows), DinoXcope (Mac OS)
Supported image formats (Windows)BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA, PCX, MNG, WBMP, JP2, JPC, PGX
Supported video formats (Windows)WMV, FLV, SWF
Supported image formats (MacOS)JPEG, PNG
Supported video formats (MacOS)MOV
Imaging standardsDirectShow, UVC
WifiYes
Housing
Housing materialComposite/plastic housing
Magnification lockNo
Dimensions10.5cm (L) x 3.2cm (D)
Weight95 g
Cable length1.8m
Features
MeasurementNo
CalibrationNo
Microtouch sensorNo
Information
Package contentsMicroscope, carry pouch, 10x 3 mm specula, 10x 4 mm specula, 10x 5 mm specula, user manual
Warranty information2 years European warranty
Regulatory approvalMedical Device Class 1 – Medical Devices Regulation (EU) 2017/745
