Dino-Lite IriScope (MEDL4R) on uus, kiire ja lihtne viis silmade pildistamiseks. IriScope'il on 2x2 LED-tuled (valge/kollane), mis valgustavad silma külge, vähendades pildi peegeldusi ja eredast valgusest tingitud ebamugavust. Kollast LED-tuld kasutades saadakse paremad pildid tumedatest iiristest. Piltide maksimaalne eraldusvõime on 1,3 megapikslit.
Lighting
Light/ LED typeWhite/ Yellow
Number of LEDs2+2
LED on/off switchable:Yes
Infrared filterIR cut-filter >650 nm
Diffuser availableNo
PolarizerNo
Optics
Magnification10-20x
Lens typeGlass with anti-reflection coating
Sensor
Sensor typeCMOS
Resolution1.3 Megapixel (1280x1024)
Maximum frame rate30 fps
Compatibility
InterfaceUSB 2.0
Operating systemWindows 7, 8, 10 & 11, MacOS 10.9 and up
SoftwareDinoCapture 2.0 (Windows), DinoXcope (Mac OS)
Supported image formats (Windows)BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA, PCX, MNG, WBMP, JP2, JPC, PGX
Supported video formats (Windows)WMV, FLV, SWF
Supported image formats (MacOS)JPEG, PNG
Supported video formats (MacOS)MOV
Imaging standardsDirectShow, UVC
Housing
Housing materialComposite/plastic housing
Magnification lockYes
Dimensions10.5cm (L) x 3.2cm (D)
Weight95 g
Cable length1.8m
Features
Special featureNo
MeasurementNo
CalibrationNo
Microtouch sensorYes
Information
Package contentsMicroscope, carry pouch, user manual
Warranty information2 years European warranty
Regulatory approvalMedical Device Class 1 – Medical Devices Regulation (EU) 2017/745
