Tugevad Tooted, IEC Pistikud ja Hülssühendid, Merenduslik Klass, Emane, Ühenduskeha, 100A 3-Faasiline Wye 277/480V AC, 4-Pooluseline 5-Juhtmeline Maandus, Klemmikruvid, Kollane.
Korrosioonikindlad seadmed, mis taluvad kõige rängemaid Keskkondi - Hubbell pakub kõrgekvaliteedilisi 100A IEC pistiku ja hülssühendeid, mis on mõeldud kasutamiseks kõige nõudlikumates keskkondades. Nendel seadmetel on nikkeldatud täismessingist kontaktid pika eluea ja usaldusväärse elektriühenduse tagamiseks kõige korrosiivsemates keskkondades. Neil on hästi nähtav kollane ülitugev nailonkorpus. Robustsed välised juhtmeklambrid tagavad maksimaalse juhtme kinnituse, et säilitada kindlad ühendused. Kruvid ja kinnitusdetailid on valmistatud roostevabast terasest.
- Isoleeritud mittemetallist korpus.
- Ise sulguv tihendatud kaas.
- Värvikoodiga korpused lihtsaks tuvastamiseks.
General
Application Marine Wiring Devices
Catalog Number M5100C7R
Color Yellow
Environmental Conditions Watertight
EU RoHS Indicator Yes
Insulation Insulated Body
Item Type Standard
Material - Mounting Hardware Cord Mounted
Number Of Poles 4-Pole
OEM Brand Name Hubbell Wiring Device-Kellems
Performance
Electrical - Current Interrupting - Certified for current interrupting at full rated current
Electrical - Dielectric Voltage - Withstand 3000V AC
Electrical - Max. Working Voltage - 600V RMS
Environmental - Flammability - HB or better per UL 94 or CSA C22.2 No. 0.17
Environmental - Ingress Protection - IP67 Suitability
Environmental - Moisture Resistance - Watertight per IEC 60309-1
Environmental - Operating Temperatures - Maximum Continuous 75°C
Minimum - 40°C w/o impact
Mechanical - Impact Resistance - Per CSA C22.2 No. 182.1 / UL1682
Mechanical - Product Identification - Ratings are a permanent part of the device housing
Mechanical - Terminal Identification - Terminals identified in accordance with North American and IEC conventions
Series Corrosion Resistant
Specifications
Cord Clamps - Reinforced Thermoplastic Polyester
Covers - Reinforced Thermoplastic Polyester
Gaskets - Solid Neoprene
Glands - Solid Neoprene
Housing - Zytel® ST801 Nylon
Style Reverse Service
Temperature Rating Maximum Continuous: 75° C; Minimum Continuous: -40° C w/o impact, -25° with impact.
Type Watertight Connector Body
UPC 783585510088
Dimensions
Display Size Standard
Electrical Ratings
Amperage Rating 100 A
Connectivity Pressure Terminal Screws
Current / Amperage Rating 100 A
Current Rating 100 A
Voltage Rating 3 Phase Y 277/480 VAC
Voltage Rating Description 3 Phase Y 277/480 VAC
Conductor Related
Conductor Range #3 AWG to #1/0 AWG
Number of Conductors 5-Wire Grounding
Number Of Wires 5-Wire
Certifications And Compliance
Industry Standard(s)
CSA Certified File LR280C
UL Classified to IEC 60309-1 IEC 60309-2
UL Listed, File E146033
Nema Rating Non-NEMA
