Ambient Relative Humidity |
5 to 95%, (non-condensing) |
|
Certifications |
FCC, CE, UL/cUL 508, ISA 12.12.01, Class 1 Div 2 |
|
Connection |
1 removable 4-contact terminal block |
|
Dimensions |
30 x 142 x 99 mm (1.18 x 5.59 x 3.90 in.) |
|
EMI |
FCC Class A |
|
EMS |
EN6100-4-2; EN6100-4-3; EN6100-4-4; EN6100-4-5; EN6100-4-6; EN6100-4-8
EN6100-6-2; EN6100-6-4 |
|
EMS |
EN6100-4-2; EN6100-4-3; EN6100-4-4; EN6100-4-5; EN6100-4-6; EN6100-4-8
EN6100-6-2; EN6100-6-4 |
|
Fiber Port |
1*100Fx SC type connectorMulti-mode (2Km) - 50/125um ~ 62.5/125um |
|
Flow Control |
IEEE 802.3x flow control, back pressure flow control |
|
Free Fall |
IEC60068-2-32 |
|
Green |
RoHS Compliant |
|
Housing |
Metal, IP30 protection |
|
Input Voltage |
48~55VDC, Redundant Input |
|
MAC Table Size |
2K |
|
Mounting |
DIN-Rail mounting, wall mounting (optional) |
|
Operating Temperature |
STD: -10° to 70° C (14° to 158° F) |
|
Overload Current Protection |
Slow-Blown Fuse |
|
PoE Pin Out |
V+, V+, V-, V-, for pin 1, 2, 3, 6 (Endspan, MDI-X Alternative A) |
|
PoE Power Output |
25W @ 48VDC (per PoE port); 30W @ 51~55VDC (per PoE port) |
|
Power Consumption |
110 Watts @ 48VDC; 130 Watts @ 51~55VDC |
|
Processing Type |
Store and Forward |
|
Reverse Polarity Protection |
Yes |
|
RJ45 Ports |
10/100BaseT(X) auto negotiation speed, Full/Half duplex mode, and auto MDI/MDI-X connection
4*10/100Tx (PoE+) |
|
Shock |
IEC60068-2-27 |
|
Standards |
IEEE 802.3 10BaseT Ethernet
IEEE 802.3u 100BaseTX Fast Ethernet
IEEE802.3x Flow Control and Back-Pressure
IEEE 802.3at Power over Ethernet |
|
Storage Temperature |
-40°C ~ 85°C (-40°F ~ 185°F) |
|
Switching Architecture |
Back-Pane (Switching Fabric): 1.9 GbpsPacket Throughout Ability (Full-Duplex): 1.488Mpps @64bytes |
|
Technology Protocol |
CSMA/CD |
|
Transfer Rate |
14,880pps for Ethernet Port148,800pps for Fast Ethernet Port |
|
Vibration |
IEC60068-2-6 |
|
Warranty |
5 Years |
|
Wavelength |
1310nm (Multi-mode) |
|
Weight |
Unit Weight: 1.1 lbs. Shipping Weight: 1.45 lbs |
