CAT6A kaabel on muutumas paljude struktureeritud kaabeldusvõrkude valikukaabliks. CAT6A kaabel võimaldab edastada kuni 10 Gbps ja sellest on kiiresti saamas VoIP, CCTV ja andmevõrkude kaabeldustaristu.
|
Cable structure |
Li02YSCH 4x2xAWG 27/7 PiMF |
|
Jacket diameter |
5.8 mm (±0.2 mm) |
|
Life (mating cycles RJ45, RJ12, RJ11) |
≥ 750 |
|
Stranded wire |
AWG 27 (7/0.14 mm) |
|
Insulation |
PE, Ø 1.02 mm (±0.05 mm) |
|
Pair shielding |
Al-foil, outside conducting |
|
Overall shielding |
tin plated copper braid |
|
Climatic Characteristics |
|
UL |
E244889 |
|
flame-retardant test |
IEC 60332-1 |
|
Operating temperature in °C |
-40°C to 75°C |
|
Electrical Characteristics |
|
PoE+ acc to IEEE 802.3at |
Adequate for Power over Ethernet+ |
|
Current carrying capacity at 50°C |
1 A |
|
Standards |
|
Connectors |
IEC 60603-7-51 |
|
|
10 Gigabit Ethernet acc. to IEEE 802.3an |
Adequate for 10 Gigabit Ethernet |
