Switch: 12 x 10/100/1000BaseT(X) PoE+, 4 x SFP, -40 kuni 80°C, mittemanageeritav, DIN, 48-55VDC

Switch: 12 x 10/100/1000BaseT(X) PoE+, 4 x SFP, -40 kuni 80°C, mittemanageeritav, DIN, 48-55VDC

Certifications	FCC, CE
Connection	1 removable 6-contact terminal block
Dimensions	59 x 99 x 142 mm (WDH)
EMS	EN61000-4-2,3,4,5,6,8 EN61000-6-2,4
Ethernet Port	12*RJ45 Ports w/10/100/1000Tx (w/PSE: 30W/port), auto negotiation speed, Full/Half duplex, and auto MDI/MDIX connection
Fiber Port	4*100/1000 SFP Slots
Flow Control	IEEE 802.3x back pressure flow control
Free Fall / Shock / Vibration	IEC60068-2-32 / IEC60068-2-27 / IEC60068-2-6
Green	RoHS Compliant
Housing / Mounting	Metal, IP30 protection / DIN-Rail and wall mounting Provided
Input Voltage	48~55VDC, Redundant Input
Jumbo Frame	12.2Kbytes
MAC Table Size	8K
Memory Buffer	4 Mbit
Operating Temperature	EOT: -40° to 75°C
Overload Current Protection	Present (Slow-Blown Fuse)
Power Consumption	16W; (376W w/full PSE load)
Processing Type	Store and Forward
Protocols	CSMA/CD
Reverse Polarity Protection	Yes
Standards	IEEE 802.3 10BaseTx Ethernet IEEE 802.3u 100BaseTx Fast Ethernet IEEE 802.3ab 1000BaseTx IEEE 802.3z Gigabit Fiber IEEE 802.3af/at Power over Ethernet
Storage Temperature	-40°C ~ 85°C
Switching Architecture	Back-Plane (Non-Block Switching Fabric)
Transfer Rate	14,880pps for Ethernet Port 148,800pps for Fast Ethernet Port 1,488,000pps for Gigabit Ethernet Port
Warranty	5 Years

1 425,00 € (ilma km-ta)

Lisa ostukorvi

Lisa soovinimekirja

Müügitingimused
Hinnad ei sisalda käibemaksu.

Dokumendid

Antaira_LNP-1604G-SFP series_Datasheet-v1.1.pdf

Manufacturer Part Number: LNP-1604G-SFP-T
Tootekood: EE-100-169-990

Spetsifikatsioon

Weight

1.36 kg
