Specifications
AV Interface: HDMI
Interface Standard: HDMI 2.0
Supported Bandwidth: 18Gbps
Maximum Distance: 300m (984.24ft)
Maximum Resolution: 3840x2160@60Hz 4:4:4 8bit
HDCP Support: Pass-through
EDID Pass Through: Pass-through
Supported Audio: Pass-through
Transmission Medium: 1 x Duplex LC (50/125µm)
Laser Class (only for Fibre): 1
Wavelength (only for Fibre): 850nm
Special Features: Auto Laser Disabling Function
Connectors
Transmitter Input: HDMI Type A (Male)
Transmitter Output: Duplex LC
Receiver Input: Duplex LC
Receiver Ouput: HDMI Type A (Male)
Power: USB Micro-B
Physical Properties
Dimensions (approx.) WxDxH: 30x124.5x11.3mm (1.18x4.9x0.44in) per unit
Housing Material: Metal
Net Weight: 0.145kg (0.32lb) per unit
Operating Temperature: 0°C - 50°C (32°F - 122°F)
Storage Temperature: 10°C - 70°C (14°F - 158°F)
Humidity: 0-85% RH (non-condensing)
Power Requirements: 5V DC 1A
Colour: Black
Miscellaneous
Packaging Type: Carton box
Packaging Dimensions: 220x50x160mm (8.66x1.97x6.3in)
Gross Weight: 0.56kg (1.23lb)
Warranty (Years): 2
Certificated: CE, FCC, RoHS, REACH & California Proposition 65
Package Content
Transmitter unit
Receiver unit
2 x USB A/Micro-B cable, 1m
Lindy manual
