Connectors
Connector A: Micro-HDMI Male
Connector B: Micro-HDMI Male
Housing Material: Zinc Alloy
Connector Plating: Gold Plated
Pin Construction: Gold-Plated Brass
Pin Plating: Gold Plated
Dimensions (approx.) WxDxH:
Micro-HDMI Connector: 44.2x12.7x7.1mm (1.74x0.5x0.28in)
HDMI Connector: 48.2x20x10mm (1.9x0.79x0.39in)
DVI Connector: 43x40x14.5mm (1.69x1.57x0.57in)
Cable Construction
Length: 50m (164.04ft)
Standard: HDMI 2.0
Colour: Black
Type: Round
Jack Diameter: 6mm (0.24in)
Jack Material: PVC
Conductor Material: Gold Plated Copper
Conductor Gauge: 24AWG
Shielding: Aluminium Mylar
Specifications
Supported Bandwidth: 18Gbps
Maximum Resolution: 4096x2160@60Hz 4:4:4 8bit
Nominal Attenuation: -1dB~-2dB
Minimum Bend Radius: 60mm (2.36in)
Operating Temperature: 0°C - 50°C (32°F - 122°F)
Storage Temperature: -20°C - 85°C (-4°F - 185°F)
Miscellaneous
Packaging Type: Carton box
Warranty (Years): 2
Certificated: CE, FCC, RoHS, REACH & California Proposition 65
