Tööstuslik konverter, Ethernet - VDSL2, 10/100/1000Mbps 30a profiiliga

Tööstuslik konverter, Ethernet - VDSL2, 10/100/1000Mbps 30a profiiliga

Address Table	2K
Ambient Relative Humidity	10 - 90% (non-condensing)
Certifications	FCC Part 15 Class A, CE
Dimensions	97 x 70 x 26mm (WDH)
Dip Switch	4-position DIP switch - CO/CPE mode selectable - Selectable G.INP and interleaved mode - Selectable target band plan - Selectable target SNR mode
Ethernet Port	1*10/100/1000Tx RJ45 auto MDI/MDI-X port
Flow Control	Back pressure for half duplex IEEE 802.3x pause frame for full duplex
Free Fall / Shock / Vibration	IEC60068-2-32 / IEC60068-2-27 / IEC60068-2-6
Housing	Metal
Input Voltage	5VDC, 2A
Jumbo Frame	9Kbytes
LED Indicators	Power: Green 1000Base-Tx Link/Act: Green 100Base-Tx Link/Act: Green VDSL: Green CO: Green CPE: Green
Operating Temperature	0° ~ 50°C
Phone Port	Additional Splitter for POTS connection
Power Connection	AC power adapter
Power Consumption	3.5 Watts/11.93 BTU @ AC 110V (full loading) 3.6 Watts/12.28 BTU @ AC 220V (full loading)
Standards	IEEE 802.3 Ethernet IEEE 802.3 Fast Ethernet IEEE 802.3ab Gigabit Ethernet IEEE 802.3x Full-duplex flow control IEEE 802.1p Class of Service ITU-T G.993.1 VDSL ITU-T G.997.1 ITU-T G.993.2 VDSL2 (Profile 17a/30a Support) ITU-T G.993.5 G.Vectoring & G.INP ITU-T G.998
Storage Temperature	-40° ~ 70°C
Switching Architecture	Store-and-Forward
VDSL Port	1*VDSL2 RJ11 female phone jack Twisted-pair telephone wires (AWG24 or better) up to 1.4km
Warranty	2 Years
Weight	Unit: 0.88 lbs.; Shipping: 1.0 lbs.

195,00 € (ilma km-ta)

Lisa ostukorvi

Lisa soovinimekirja

Müügitingimused
Hinnad ei sisalda käibemaksu.

Dokumendid

Antaira_EVC-3101 Datasheet-v1.0.pdf

Manufacturer Part Number: EVC-3101
Tootekood: EE-100-169-734

Spetsifikatsioon

Weight

0.18 kg
