PoE injector: 10/100/1000BaseT(X) Type 3 PPoE, -40° kuni 75°C

Ambient Relative Humidity 5% to 95%, (non-condensing)
Certifications FCC, CE, UL (Pending)
Dimensions 26 x 95 x 75 mm (W x H x D)
EMI CE, FCC Class A
EN61000-6-4, EN61000-6-2, EN61000-4-2 (ESD), EN61000-4-3 (RS), EN61000-4-4 (EFT), EN61000-4-5 (Surge), EN61000-4-6 (CS), EN61000-4-8 (Magnetic Field)
Ethernet Port 2*10/100/1000BaseT(X)
(1*Data IN, 1*PoE OUT)
Free Fall IEC60068-2-32
Green RoHS Compliant
Housing Metal, IP30 protection
Input Voltage 9~48VDC, Power Inputs
LED Indicators Power and PoE
Max. PoE Power Budget 60Watts
Mounting DIN-Rail Mounting, Wall Mounting
Operating Temperature EOT: -40°C ~ 75°C
Overload Current Protection Present
PoE Port Pin Assignment V+ for pin 3, 4, 5, 6
V- for pin 1, 2, 7, 8
PoE Power Output 60W max. per PoE port
Power Connection 4-pin terminal block
Power Consumption 5Watts for system
Reverse Polarity Protection Present
Shock IEC60068-2-27
Standards IEEE 802.3 10BaseT Ethernet
IEEE 802.3u 100BaseTX Fast Ethernet
IEEE 802.3ab 1000BaseT(X)
IEEE 802.3af/at/bt Power over Ethernet
Storage Temperature -40°C ~ 85°C
Transfer Rate 14,880pps for Ethernet Port
148,800pps for Fast Ethernet Port
1,488,000pps for Gigabit Ethernet Port
Vibration IEC60068-2-6
Warranty 5 Years
Weight Unit: 0.60 lbs.
Shipping: 1.0 lbs.
229,00 € 229,00 € (ilma km-ta)

 Lisa ostukorvi
Müügitingimused
Hinnad ei sisalda käibemaksu.
Dokumendid
Antaira_INJ-0200G-60-24-T Datasheet_v1.0.pdf

Manufacturer Part Number: INJ-0200G-60-24-T
Tootekood: EE-100-169-633
