Toiteplokk DIN-liistule 36W 24V 1.5A -30 kuni 70C°

Name: [HDR-30-24] Toiteplokk DIN-liistule 36W 24V 1.5A -30 kuni 70C°
SKU: EE-100-184-625
Price: 12.5 EUR
Availability: InStock

AC-DC Ultra slim DIN rööpmel toiteallikas; sisendvahemik 85-264VAC; väljund 24VDC 1,5A juures; Pass LPS

Ülimalt õhuke: ainult 35 mm lai

Universaalne vahelduvvoolu sisend

Koormuseta energiatarbimine <0,3W

Reguleeritav väljundpinge

LED-indikaator sisselülitamiseks

Technical data		Information
Brand	Mean Well	Commodity	8504409090
Item number	HDR-30-24	Warranty pack	36 Months Bring-In
Series	HDR-30	RoHS	Compliant
Description	AC-DC Ultra slim DIN rail power supply; Input range 85-264VAC; Output 24VDC at 1.5A; Pass LPS	Packing quantity	96
Application	Installation UL 508 ITE EN/UL/IEC 60950	Net weight (gram)	140
Technology	AC/DC
Power Format	DIN rail
Output Power (W)	30
Output Voltage (V)	24
Output Current (A)	1.5
Input Voltage (V)	85 - 264 Universal Input 110/230V
IP Rating	No IP assigned
Width (mm)	35
Height (mm)	90
Depth (mm)	54.5
Dimming Technology	No Dimming

12,50 € (ilma km-ta)

Müügitingimused
Hinnad ei sisalda käibemaksu.

Dokumendid

HDR-30-spec.pdf

Manufacturer Part Number: HDR-30-24
Tootekood: EE-100-184-625

Weight

0.15 kg
