IIoT ja Industry 4.0 valdkonnas vajavad üha enam kliendid andmete visualiseerimist, et hõlbustada protsesside juhtimist ja otsuste tegemist. FPM-215W on tööstusliku tasemega laiekraanmonitor, millel on elegantsed, lihtsad jooned ja täiesti lame puutetundlik ekraan. FPM-215W on varustatud P-CAP 10-punktilise multitouch-juhtimise ja IP66-klassiga esipaneeliga ning on mõeldud intuitiivseks kasutamiseks tööstuslikes keskkondades, nagu nutikad tehased ja masinaautomaatika ekraanid.
General
Certification BSMI, CCC, CE, FCC Class A, UL, CB
Dimensions (W x H x D) 419.7 x 269 x 56.2 mm (16.52" x 10.59" x 2.21")
Enclosure Front panel: Die-casting aluminium,
Rear cover: Die-casting aluminium
Mounting Panel, VESA arm
Power Input External 60 W power adapter, with AC 100 V ~ 240 V
input and DC +12 V @ 5 A output (included)
Video Port HDMI
Weight (Net) 4kg (8.82 lb)
LCD Display
Display Type FHD TFT LED LCD
Display Size 15.6"
Max. Resolution 1920 x 1080
Max. Color 16.7M
Viewing Angle (H/V)° 178/178
Luminance (cd/m2
) 350
Backlight Life (hrs) 50,000
Contrast Ratio 1000:1
Touchscreen
Type Projected capacitive touch
Interface USB
OS Support Windows® 7, 8, 10,11, XPe, CE and Linux
Hardness 7H
Multi Touch 10 points, USB interface in Win 7/8/10, Linux
15.6" FHD TFT LED LCD with true-flat touchscreen
16:9 wide screen aspect ratio, increases viewing area by 40%
Supports 10-point multi-touch control via USB interface in Windows 7/8/10
OS
Slim design enables easy installation
Supports various mount options: panel, desktop, and VESA arm
Touchscreen with reliable glass surface and P-CAP touch control
Robust system with Die-casting aluminum chassis and IP66-rated aluminum
alloy front bezel
Lockable I/O connectors
Environment
Operation Temperature 0 ~ 50°C (32 ~ 122°F)
Storage Temperature -20 ~ 60°C (-4 ~ 140°F)
Humidity (Storage) 10 ~ 95% non-condensing
Waterproof Front Panel IP66 Compliant
Vibration 5 ~ 500 Hz, 1 Grms (Operating, Random)
Ordering Information
FPM-215W-P4BE 15.6" FHD Ind. Monitor, w/ PCAP touch (Adapter
included) (Made in China)
FPM-215W-P4BU 15.6" FHD Ind. Monitor, w/ PCAP touch (Adapter
included) (Made in Taiwan)
Optional Accessories
1702002605 Power Cable EU Plug 1.8 M
1702031801-11 Power Cable UK Plug 1.8 M
1700000596-11 Power Cable China/Australia Plug 1.8 M
1702002600 Power Cable US Plug 1.8 M
FPM-200W-ADKE Adapter bracket for FPM-200W
Mounting kit
FPM-1000T-SMKE Desktop Mounting kit for FPM series
PPC-174T-WL-MTE Wall mount kit A800B
PPC-ARM-A03 ARM VESA Standard (A-CLEVER)
PPC-STAND-A1E Stand mounting kit
