IIoT ja Industry 4.0 valdkonnas vajavad üha enam kliente andmete visualiseerimist, et hõlbustada protsesside juhtimist ja otsuste tegemist. FPM-200 seeria on tööstusliku tasemega monitor, millel on elegantsed, lihtsad jooned ja täiesti lame puutetundlik ekraan. FPM-200 seeria on varustatud vastupidava resistiivse puutetundliku juhtimise ja IP66-klassiga esipaneeliga ning on mõeldud intuitiivseks kasutamiseks tööstuslikes keskkondades, nagu nutikad tehased ja masinate automatiseerimise ekraanid.
Specifications
General
Certification BSMI, CCC, CE, FCC, UL, CB
Dimensions (W x H x D) FPM-212: 311.8 x 238.0 x 53 mm
(12.27 x 9.37 x 2.08 in)
FPM-215: 383.2 x 307.3 x 53.20 mm
(15.08 x 12 x 2.09 in)
FPM-217: 410.4 x 343.4 x 54 mm
(16.15 x 13.51 x 2.12 in)
FPM-219: 454 x 379.8 x 51.5 mm
(17.87 x 14.95 x 2.03 in)
Enclosure Front panel: Die cast magnesium alloy
Rear cover: Die-casting aluminum
Mount Options Stand, Wall, Panel and VESA arm (75 x 75mm)
Power Input FPM-2XX-R8AE : External 36 W power adapter, with AC 100
V ~ 240 V input and DC +12 V @ 3 A output (included)
FPM-2XX-R9AE: Terminal Block: 24 VDC input
Video Port HDMI, DP, and VGA
Weight (Net) 3.2 kg / 4.6 kg / 5.4 kg / 6.2 kg
Power Consumption
FPM-212-R8AE 17.91(idle), 19.01(Max)
FPM-215-R8AE 14.69(idle), 15.32(Max)
FPM-217-R8AE 12.04(idle), 14.56(Max)
FPM-212-R9AE 16.65(idle), 17.51(Max)
FPM-215-R9AE 14.19(idle), 14.75(Max)
FPM-217-R9AE 11.92(idle), 14.19(Max)
FPM-219-R9AE 14.19(idle), 15.53(Max)
LCD Display
Display Type XGA/XGA/SXGA/SXGA TFT LCD
Display Size 12"/15"/17"/19"
Max. Resolution 1024 x 768/1024 x 768/1280 x 1024/1280 x 1024
Max. Color 16.2M/16.2M/16.7M/16.7M
Viewing Angle (H/V °) 178/178, 176/176, 178/178,170/160
Luminance (cd/m2
) 600/300/250/350
Backlight Life 50,000/70,000/50,000/50,000 hr
Contrast Ratio 1000:1 / 2000:1 / 1000:1/1000:1
Touchscreen
Type 5-wire analog resistive
Interface USB
Light Transmission Above 75%
OS Support Windows XP, Vista, 7, 8,10,11, XPe and Linux
Environment
Operating Temperature 0 ~ 50 °C (32 ~ 122 °F)
Storage Temperature -20 ~ 60 °C (-4 ~ 140 °F)
Humidity (Storage) 10 ~ 90% non-condensing
IP Rating IP-66 graded front panel
Vibration 5 ~ 500 Hz, 1 Grms (Operating, Random)
Ordering Information
FPM-212-R8AE 12.1" XGA Ind. Monitor, w/Resistive TS (Made in China)
FPM-212-R8AU 12.1" XGA Ind. Monitor, w/Resistive TS (Made in Taiwan)
FPM-215-R8AE 15" XGA Ind. Monitor,w/Resistive TS (Made in China)
FPM-215-R8AU 15" XGA Ind. Monitor,w/Resistive TS (Made in Taiwan)
FPM-217-R8AE 17" SXGA Ind. Monitor,w/Resistive TS (Made in China)
FPM-217-R8AU 17" SXGA Ind. Monitor,w/Resistive TS (Made in Taiwan)
FPM-212-R9AE 12.1" XGA Ind. Monitor, w/Resistive TS (24 VDC)
(Made in China)
FPM-212-R9AU 12.1" XGA Ind. Monitor, w/Resistive TS (24 VDC)
(Made in Taiwan)
FPM-215-R9AE 15" XGA Ind. Monitor,w/Resistive TS(24 VDC)
(Made in China)
FPM-217-R9AE 17" SXGA Ind. Monitor,w/Resistive TS(24 VDC)
(Made in China)
FPM-219-R9AE 19" SXGA Ind. Monitor,w/Resistive TS(24 VDC)
(Made in China)
Optional Accessories
12VDC version Power cord
1700001524 Power Cable US Plug, 1.8m
170203183C Power Cable EU Plug, 1.8m
170203180A-01 Power Cable UK Plug, 1.8m
1700008921 Power Cable JP Plug, 1.8m
1700019146 Power Cable China/Australia Plug, 1.8m
24VDC version Power cord and adapter
1702002600 Power Cable US Plug 1.8 M
1702002605 Power Cable EU Plug 1.8 M
1702031801-11 Power Cable UK Plug 1.8 M
1700000596-11 Power Cable China/Australia Plug 1.8 M
PWR-247-DE Adapter 100-240V 60W 24V 2.5A
FPM-200W-ADKE Adapter bracket for FPM-200W (Note: Only 17" and 19" supported)
Mounting kit
FPM-1000T-SMKE Desktop/Wall Mounting kit for FPM series
PPC-174T-WL-MTE Wall mount kit A800B
PPC-ARM-A03 ARM VESA Standard (A-CLEVER)
PPC-STAND-A1E Stand mounting kit
FPM-715-RMKE FPM-715 Rack-Mount Kit (Note: Only 15" supported)
FPM-717-RMKE FPM-717 Rack-Mount Kit (Note: Only 17" supported)
