| Specifications | | Voltage DC | | Range: | 6.000V - 1000V | | Best Accuracy: | +/- (0.3 % + 1) | | Best Resolution: | 0.1 mV |
| | Voltage AC | | Range: | 600.0 mV-1000V | | Best Accuracy: | +/- (2.0 % + 2) | | Best Resolution: | 1.0 mV |
| | Amps AC | | Range: | 60.00 mA – 10A | | Best Accuracy: | 2.5 % + 2 | | Best Resolution: | 0.01mA |
| | Amps DC | | Range: | 60.00 mA – 10A | | Best Accuracy: | 1.5 % + 2 | | Best Resolution: | 0.01 mA |
| | Resistance | | Range: | 600.0 ? - 50 M? | | Best Accuracy: | +/- (0.5 % + 1) | | Best Resolution: | 0.1? |
| | Capacitance | | Range: | 1nF- 9,999 µF | | Best Accuracy: | +/- (1.2 % + 2) | | Best Resolution: | 1 nF |
| | Frequency | | Range: | 99.99Hz- 99.99kHz | | Best Accuracy: | +/- (0.1 % + 1) | | Best Resolution: | 0.01Hz |
| | Safety |
| ANSI/ISA S82.02.01, CSA C22.2-1010.1, IEC 61010 to 1000 V Measurement Category III, 600 V Measurement Category IV |
| | Certifications |
| CSA, TÜV (EN61010), UL, Π, ; (N10140),VDE |
|
| General Specifications | | Maximum voltage between any terminal and earth ground | | | Surge protection | | | Ω Fuse for mA inputs | | | Ω Fuse for A inputs | | | Display | | Digital: | 6000 counts, updates 4/sec | | Bar Graph: | 33 segments; Updates 32/sec | | Frequency: | 10,000 counts | | Capacitance: | 1,000 counts |
| | Altitude | | Operating: | 2,000 meters | | Storage: | 12,000 meters |
| | Temperature | | Operating: | -10 °C to +50 °C | | Storage: | -40 °C to +60 °C |
| | Temperature Coefficient |
| 0.1 X (specified accuracy / °C (< 18 °C or > 28 °C) |
| | Electromagnetic Compatibility (EN 61326-1:1997) |
| In an RF field of 3 V/M, accuracy = specified accuracy except in temperature: specified accuracy ± 5 °C (9 °F) |
| | Relative Humidity (Maximum Non-condensing) |
| 90 % to 35 °C |
| 75 % to 40 °C |
| 45 % to 50 °C |
| | Battery Life |
| 400 Hours Typical (Alkaline) |
| | Size | | Height: | 4.3 cm | | Width: | 9 cm | | Length: | 18.5 cm |
| | Weight | |
|
|
| |
