Image Presentation and Modes |
|
4", 640 x 480 pixel touch screen LCD with auto-rotation |
| |
|
Iron, Gray, Rainbow, Arctic, Lava, Rainbow HC |
|
Infrared, visual, MSX ®, Picture-in-Picture |
| |
|
Embosses visual details on full resolution thermal image |
|
Iron, Gray, Rainbow, Arctic, Lava, Rainbow HC |
|
|
±2°C (±3.6°F) or ±2% of reading for ambient temperature 15°C to 35°C (59°F to 95°F) and object temperature above 0°C (32°F) |
|
Moisture alarm, insulation alarm, measurement alarms |
|
Above/below/interval/condensation/insulation |
Laser Distance Measurement | |
|
No measurement, center spot, hot spot, cold spot, User Preset 1, User Preset 2 |
|
Yes; automatic GPS image tagging |
|
| |
|
Standard JPEG with measurement data included |
Video Recording and Streaming |
Radiometric IR Video Recording |
Real-time radiometric recording (.csq) |
Non-Radiometric IR Video Recording / Visual Video Recording | |
Radiometric IR Video Streaming | |
Non-Radiometric IR Video Streaming |
H.264 or MPEG-4 over WiFi
MJPEG over UVC or WiFi |
|
| |
|
DisplayPort over USB Type-C |
|
|
Li ion battery, charged in camera or on separate charger |
|
Approx. 2.5 hours at 25°C (77°F) ambient temperature and typical use |
|
Operating Temperature Range |
–15°C to 50°C (5°F to 122°F) |
Storage Temperature Range |
–40°C to 70°C (-40°F to 158°F) |
Shock/Vibration/Encapsulation; Safety |
25 g / IEC 60068-2-27, 2 g / IEC 60068-2-6, IP 54 /IEC 60529; EN/UL/CSA/PSE 60950-1 |
Weight/Dimensions w/o Lens |
1 kg (2.2 lbs), 27.8 x 11.6 x 11.3 cm (11.0 x 4.6 x 4.4 in) |
