| Mechanical |
|---|
| Dimensions | 250 x 250 x 43.5 mm (9.8 x 9.8 x 1.7") |
| Weight | 1.8 kg (4 lb) |
| Enclosure material | UV-stabilized polycarbonate, aluminum alloy |
| Mount material | Stainless steel (SUS304), galvanized steel (SGCC) |
| Hardware |
|---|
| Networking interface | (1) 10 GbE RJ45 port
(1) 1 GbE RJ45 port |
| Management interface | Ethernet | |
| Power method | PoE++ |
| Power supply | UniFi PoE switch |
| Supported voltage range | 42.5—57V DC |
| Max. power consumption | 43W |
Max. TX power
2.4 GHz
5 GHz
6 GHz |
23 dBm
30 dBm
24 dBm / 30* dBm
*With 6 GHz Extended Range mode. Available in FCC/IC region only. |
MIMO
2.4 GHz
5 GHz
6 GHz |
2 x 2 (DL/UL MU-MIMO)
4 x 4 (DL/UL MU-MIMO)
4 x 4 (DL/UL MU-MIMO) |
Max. data rate
2.4 GHz
5 GHz
6 GHz |
688 Mbps (BW40)
8.6 Gbps (BW240)
11.5 Gbps (BW320) |
Antenna gain
2.4 GHz
5 GHz
6 GHz |
5 dBi
6 dBi
6 dBi |
| Antenna | Internal with omni patterns |
| LEDs | R/G/B |
| Button | Factory reset |
| Mounting | Wall/ceiling (Included) |
| Ambient operating temperature | -30 to 50° C (-22 to 122° F) |
| Ambient operating humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| Software |
|---|
| WiFi standards | 802.11a/b/g/n/ac/ax/be (WiFi 6, WiFi 7) |
| Wireless security | WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK) |
| BSSID | 8 per radio |
| VLAN | 802.1Q |
| Advanced QoS | Per-user rate limiting |
| Guest traffic isolation | Supported |
| Concurrent clients | 1,000+ |
| Ubiquiti specific features | Dedicated spectral analyzer radio |
| Supported Data Rates |
|---|
| 802.11a | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| 802.11b | 1, 2, 5.5, 11 Mbps |
| 802.11g | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| 802.11n | 6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40) |
| 802.11ac | 6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160) |
| 802.11ax (WiFi 6) | 7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160) |
| 802.11be (WiFi 7) | 7.3 Mbps to 11.5 Gbps (MCS0 - MCS13 NSS1/2/3/4, EHT 20/40/80/160/240/320) |
| Application Requirements |
|---|
| UniFi Network | Version 8.6.9 and later |
| UniFi OS | Version 4.0.20 and later |
