DPP15-100 seeria 15-100W, 5-48V väljundiga DIN rööbasteele paigaldatavad toiteallikad
Peamised turusegmendid ja rakendused
- Tööstusjuhtimine: Mootorite juhtimissüsteemid
- Tehaseautomaatika: Autotööstus, autotööstus, keemiline töötlemine
- Testimine ja mõõtmine: Mõõtmine, mõõteriistade mõõtmine
Electrical Characteristics
- Input Single-phase
- Input Voltage Range[AC] 85 to 264Vac
- Efficiency 80% Typ.
- Rated Output Voltage[DC] 24Vdc
- Output Voltage Range[DC] 22.5 to 28.5Vdc
- Maximum Output Current 630mA
- Maximum Output Power 15W
Package Type & Size
- Package / Mounting DIN rail
Industry Standard Size
- Width(W) 23mm Nom. (0.91in Nom.)
- Height(H) 75mm Nom. (2.95in Nom.)
- Depth(D) 97mm Nom. (3.82in Nom.)
- Weight 130g Typ. (0.3lbs Typ.)
Other
- Operating Temp. Range -10 to 71°C
- Cooling Convection
- Safety Standard(Certified)
EN60950-1
UL60950-1
EN62368-1
UL62368-1
UL508
UL1310 Class 2
- Safety Standard(Conformed)
Remarks
- This page only shows representative characteristics. Please refer to the technical data for detailed specifications and conditions.
