DC/DC konverter 480W 67.2~154V-24V 20A

Name: [DDR-480D-24] DC/DC konverter 480W 67.2~154V-24V 20A
SKU: EE-100-184-542
Price: 178.4 EUR
Availability: InStock

DC-DC Ultra õhuke tööstuslik DIN rööpkonverter; sisend 67,2-154Vdc; ühekordne väljund 24Vdc 20A juures; DC OK ja kaugjuhtimine ON/OFF

Technical data Information

Brand

MEAN WELL

Commodity

8504409590

Item number

DDR-480D-24

Warranty pack

36 Months Bring-In

Series

DDR-480

RoHS

Compliant

Description

DC-DC Ultra slim Industrial DIN rail converter; Input 67.2-154Vdc; Single Output 24Vdc at 20A; DC OK and remote ON/OFF

Packing quantity

Application

IT AV EN/UL/IEC 62368-1

Railway EN 45545-2

Transport EN 50155

Net weight (gram)

1375

Technology

DC/DC

Power Format

DIN rail

Output Power (W)

480

Output Voltage (V)

Output Current (A)

Input Voltage (V)

67.2 - 154

IP Rating

No IP assigned

Width (mm)

85.5

Height (mm)

125.2

Depth (mm)

128.5

Control Signals

DC OK

ON/OFF

Dimming Technology

No Dimming

178,40 € (ilma km-ta)

Lisa ostukorvi

Lisa soovinimekirja

Müügitingimused
Hinnad ei sisalda käibemaksu.

Manufacturer Part Number: DDR-480D-24
Tootekood: EE-100-184-542

Spetsifikatsioon

Weight

0.39 kg
