RS-422/485 PCIe kaart, Low Profile, 4 porti + DB9M kaabel (4 kV surge and 2 kV electrical isolation)

16C550C compatible

PCI Express 1.0

DB44 female

128 bytes

8

4

RS-422, RS-485

50 bps to 921.6 kbps (supports non-standard baudrates)

5, 6, 7, 8

1, 1.5, 2

None, Even, Odd, Space, Mark

None, XON/XOFF

2 kV

4 kV

Tx+, Tx-, Rx+, Rx-, GND

Tx+, Tx-, Rx+, Rx-, GND

Data+, Data-, GND

Linux kernel 2.4.x, Linux kernel 2.6.x, Linux kernel 3.x

DOS, Windows 95/98/ME/NT/2000, Windows XP/2003/Vista/2008/7/8/8.1/10 (x86/x64), Windows 2008 R2/2012/2012 R2 (x64), Windows Embedded CE 5.0/6.0, Windows XP Embedded

Solaris 10, UnixWare 7, SCO OpenServer 5, SCO OpenServer 6

3,414 mA @ 3.3 VDC

67.21 x 103 mm (2.65 x 4.06 in)

Built-in Tx, Rx LEDs for each port

0 to 55°C (32 to 131°F)

-20 to 85°C (-4 to 185°F)

5 to 95% (non-condensing)

EN 55032/24

CISPR 32, FCC Part 15B Class B

IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m
IEC 61000-4-4 EFT: Power: 1 kV; Signal: 0.5 kV
IEC 61000-4-5 Surge: Power: 2 kV; Signal: 4 kV
IEC 61000-4-6 CS: 150 kHz to 80 MHz: 3 V/m; Signal: 3 V/m
IEC 61000-4-8 PFMF

RoHS, CRoHS, WEEE

433,077 hrs

Telcordia (Bellcore) Standard TR/SR
