Toiteplokk LED 150W 48V 3.2A

AC-DC Single output LED driver Mix mode (CV+CC) with PFC; Output 48Vdc at 3A; IP67; cable output

Technical data		Information
Brand	Mean Well	Commodity	8504409090
Item number	CLG-150-48	Warranty pack	36 Months Bring-In
Series	CLG-150	RoHS	Compliant
Description	AC-DC Single output LED driver Mix mode (CV+CC) with PFC; Output 48Vdc at 3A; IP67; cable output	Packing quantity	12
Application	ITE EN/UL/IEC 60950 LED EN 61347	Net weight (gram)	1055
Technology	AC/DC Constant Current C.C. Constant Voltage C.V.	Alternative item number	XLG-150-24-A
Power Format	Box Type - Enclosed	Life cycle status	Discontinued
Output Power (W)	150
Output Voltage (V)	48
Output Current (A)	3.2
Input Voltage (V)	90 - 295 Universal Input 110/230V
IP Rating	IP20 IP21 IP30 IP40 IP42 IP50 IP64 IP65 IP66 IP67
Width (mm)	68
Height (mm)	38.8
Depth (mm)	222.2
Dimming Technology	No Dimming

39,67 € (ilma km-ta)

Müügitingimused
Hinnad ei sisalda käibemaksu.

Dokumendid

CLG-150-spec.pdf LED_EN.pdf

Manufacturer Part Number: CLG-150-48
Tootekood: EE-100-185-676
