VW seerial on kahte tüüpi LED-lampe, mida saab vahetada valge ja UV valguse vahel. Sellel mudelil on filter tagasituleva UV-valguse filtreerimiseks, et saada loomulike värvidega pilt.
Samuti saadaval 390-400 nm LED-idega (mudel AM4113T-FVW).
Lighting
Light/ LED type~375 nm UV + white
Number of LEDs4+4
LED on/off switchable:Yes
Infrared filterIR cut-filter >650 nm
Diffuser availableNo
Emission filterYes, Emission barrier filter 375 nm
PolarizerNo
Optics
Magnification20x~50x, 200x
Macro zoomNo
Working distanceStandard
Lens typeGlass with anti-reflection coating
Sensor
Sensor typeCMOS
Resolution1.3 Megapixel (1280x1024)
Maximum frame rate30 fps
Compatibility
InterfaceUSB 2.0
Operating systemWindows 7, 8, 10 & 11, MacOS 10.9 and up
SoftwareDinoCapture 2.0 (Windows), DinoXcope (Mac OS)
Supported image formats (Windows)BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA, PCX, MNG, WBMP, JP2, JPC, PGX
Supported video formats (Windows)WMV, FLV, SWF
Supported image formats (MacOS)JPEG, PNG
Supported video formats (MacOS)MOV
Imaging standardsDirectShow, UVC
WifiWireless-ready, requires the WF-10 WiFi streamer (optional)
Housing
Housing materialComposite/ plastic housing
Magnification lockYes
Dimensions10.5cm (L) x 3.2cm (D)
Weight105g
Cable length1.8m
Features
Special featureNo
MeasurementYes
CalibrationYes
Microtouch sensorYes
ESD safeNo
Information
Package contentsMicroscope, carry pouch, calibration target, user manual
Warranty information2 years European warranty
Regulatory approvalCE, FCC, ROHS
