QuSpot for Teltonika RUT955
Integrated multi-band LTE omni antenna + WiFi omni antenna + GPS antenna + place to install Teltonika RUT955 (All-in-one)
QuSpot omni LTE antenna for Teltonika RUT955 router is a perfect outdoor device for mobile and fixed installations like industrial, CCTV, hotspots, yachts, boats, campers, RV etc. It has embedded also omni Wi-Fi and GPS antenna. If you use RUT955 with QuSpot antenna, you get an integrated complete solution with embedded router and multi band antennas in one enclosure.
All antennas and Teltonika router integrated in one enclosure
Outdoor antenna works in any weather conditions, IP67
Antenna perfectly matched with the router
Passive PoE support
Easy to install
Dual SIM – significantly reduce roaming costs
|
LTE ANTENNA SPECIFICATION |
|---|
FREQUENCY
Supported LTE bands 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 12, 13, 14, 17, 18, 19, 20, 23, 25, 26, 27, 28, 33, 34, 35, 36, 37, 38, 39, 40, 41, 44, 2305-2360 |
0.694 - 0.96 GHz
1.7 - 2.2 GHz
2.2 - 2.7 GHz |
|---|
|
GAIN |
0.694 - 0.96 GHz : 2 dBi
1.7 - 2.2 GHz : 2 dBi
2.2 - 2.7 GHz : 4 dBi |
|---|
|
VSWR |
<1.60, max <2.00 |
|---|
|
BEAMWIDTH |
360°/35° ±5° |
|---|
|
POLARIZATION |
Vertical |
|---|
|
IMPEDANCE |
50 Ω |
|---|
|
WI-FI ANTENNA SPECIFICATION |
|---|
|
FREQUENCY |
2.40 - 2.50 GHz
4.70 - 6.00 GHz |
|---|
|
GAIN |
2.40 - 2.50 GHz : 6 dBi
4.70 - 6.00 GHz : 7 dBi |
|---|
|
VSWR |
<1.70, max <2.00 |
|---|
|
BEAMWIDTH |
360°/25° ±5° |
|---|
|
POLARIZATION |
Vertical |
|---|
|
IMPEDANCE |
50 Ω |
|---|
|
MECHANICAL SPECIFICATION |
|---|
|
MATERIALS |
ABS, aluminum, PTFE |
|---|
|
INGRESS PROTECTION |
IP67 |
|---|
|
DIMENSIONS |
160 x 160 x 240 mm
6.3 x 6.3 x 9.45 inch |
|---|
|
WEIGHT |
1.5 kg
3.31 lbs |
|---|
|
OPERATING TEMPERATURE |
From -40°C to 75°C
From -40°F to 167°F |
|---|
Router mounting adapter manual
