QuSpot omni LTE antenna for Teltonika RUT360 router is a perfect outdoor device for mobile and fixed installations like industrial, CCTV, hotspots, yachts, boats, campers, RV etc. It has embedded also omni Wi-Fi antennas. If you use RUT360 with QuSpot antenna, you get an integrated complete solution with embedded router and multi band antennas in one enclosure.
All antennas and Teltonika router integrated in one enclosure
Outdoor antenna works in any weather conditions, IP67
Antenna perfectly matched with the router
Frequency
0.694 - 0.96 GHz
1.7 - 2.2 GHz
2.2 - 2.7 GHz
Supported LTE/5G bands
1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 12, 13, 14, 17, 18, 19, 20, 23, 25, 26, 27, 28, 29, 30, 33, 34, 35, 36, 37, 38, 39, 40, 41, 44, 53, 59, 62, 65, 66, 67, 68, 69, 85, n80, n81, n82, n83, n84, n86, n89, n90, n95
Gain
0.694 - 0.96 GHz : 2 dBi
1.7 - 2.2 GHz : 2 dBi
2.2 - 2.7 GHz : 4 dBi
VSWR<1.60, max <2.00
Beamwidth360°/35° ±5°
PolarizationVertical
Impedance50 Ω
WI-FI ANTENNA SPECIFICATION
Frequency2.40 - 2.50 GHz
Gain6 dBi
VSWR<1.70, max <2.00
Beamwidth360°/25° ±5°
PolarizationVertical
Impedance50 Ω
MECHANICAL SPECIFICATION
MaterialsABS, aluminum, PTFE
Connector typeRJ45
Ingress protectionIP67
Dimensions160 x 160 x 240 mm
6.3 x 6.3 x 9.45 inch
Weight1.5 kg
3.31 lbs
Operating temperatureFrom -40°C to 75°C
From -40°F to 167°F
