This WLAN antenna by Delock allows the usage of different WLAN bands inside and outside.
Specification
• Connector: RP-SMA plug
• Frequency range:
2400 - 2500 MHz
5150 - 5875 MHz
• Antenna gain:
1.4 dBi @ 2400 - 2500 MHz
3.0 dBi @ 5150 - 5875 MHz
• Impedance: 50 Ohm
• Polarisation: linear, vertical
• VSWR: 2.0
• Operating temperature: -10 °C ~ 50 °C
• Housing material: polycarbonate
• Protection class: IP67
• Screw mounting with 13 mm bore hole
• Colour: white
• Dimensions (LxWxH): ca. 77 x 45 x 45 mm
• Cable: coaxial
• Cable type: ULA 100
• Cable colour: black
• Cable attenuation:
1.4 dB @ 2500 MHz per meter
2.3 dB @ 5875 MHz per meter
• Cable diameter: ca. 2.79 mm
• Cable length incl. connector: ca. 1 m
System requirements
• Device with a free RP-SMA jack
Package content
• WLAN antenna
Mounting type
Screw mounting with 13 mm bore hole
Interface
connector
1 x RP-SMA plug
Technical characteristics
Frequency range
2.400 - 2.500 GHz
4.900 - 5.875 GHz
Operating temperature
-10 °C ~ 50 °C
Polarisation
linear vertical
Physical characteristics
Cable attenuation
1.4 dB @ 2.500 GHz pro Meter
2.3 dB @ 5.875 GHz pro Meter
Cable length
1 m (incl. connectors)
