Toiteplokk 1 sisse, 2 välja CMCIII

Description:	The input is switched to the outputs via two relays. In this way, the outputs may be linked to measurement values and therefore switched automatically. Examples of potential applications include fan regulation. Manual switching via the CMC III operating interface is likewise supported. Each output is monitored individually, and various values are measured.
Benefits:	Fast connection and automatic detection via plug & play
Function principle:	For controlling and switching fans, heaters, equipment Measurement of voltage, current, power, work Switches 2 outputs Power is supplied via the CAN-BUS interface. Status display via integral LED
Material:	Plastic Front: Smooth Enclosure: Textured
Colour:	Enclosure: RAL 7035 Front: RAL 9005
Protection category IP to IEC 60 529:	IP 30
Supply includes:	CMC III Power Unit Operating manual Mounting accessories for mounting on surfaces Mounting clips for support rails
Dimensions:	Width: 138 mm Height: 40 mm Depth: 132 mm
Rated operating voltage:	100 V - 230 V, 1~, 50 Hz/60 Hz
Maximum no. of users:	CMC III Processing Unit: 16
Installation dimensions:	Installation depth: 120 mm Build depth: 12 mm
Operating temperature:	Operation (environment): +0°C...+55°C
Ambient humidity (non-condensing):	Operation (environment): 5 % - 95 %
Pre-fuse:	10 A
Connections:	Input: IEC 320 connector C14 Output: 2 x IEC 320 socket C13, switched
Number of connections:	2
Measurement range:	Voltage: 100 V - 230 V Frequency: 0 Hz - 60 Hz Amperage: 200 mA - 10 A cos φ: 0° - ±90° Active power: 46 W - 2,3 kW Energy consumption: 0 kWh - 1000000 kWh
Interfaces/connections:	Bus system: 2 x RJ45 CAN bus
