Connectors
Connector A: USB Type C Male
Connector B: USB Type C Male
Housing Material: Zinc Alloy
Connector Plating: Gold Plated
Pin Construction: Brass
Pin Plating: Gold Plated
Dimensions (approx.) WxDxH: 39mmx15mmx7.5mm (1.55 in x0.59in x0.3in)
Cable Construction
Length: 15m (49.21ft)
Standard: DisplayPort 1.2
Colour: Black
Type: Round
Jacket Diameter: 4.5mm (0.177in)
Jacket Material: PVC
Conductor Material: Tinned Copper
Specifications
Supported Bandwidth: 21.6Gbps
Maximum Resolution: 3840x2160@60Hz 4:4:4 10bit, 3840x2160@60Hz RGB 8bit
Nominal Attenuation: -1dB~-2dB
Minimum Bend Radius: 45mm (1.77in)
Operating Temperature: 0°C - 50°C (32°F - 122°F)
Storage Temperature: -25°C - 85°C (-13°F - 185°F)
Miscellaneous
Packaging Type: Carton box
Warranty (Years): 2
Certificated: CE, FCC, RoHS & REACH, California Proposition 65
