Specifications
-
AV Interface: DisplayPort
-
Interface Standard: DisplayPort 1.2
-
Supported Bandwidth: 21.6 Gbps
Maximum Distance:
-
17.5m (57.41ft) - 3840x2160@60Hz
-
30m (98.42ft) - 2560x1600@60Hz
Maximum Input Distance:
-
10m (32.81ft) - 3840x2160@60Hz
-
15m (49.21ft) - 2560x1600@60Hz
Maximum Output Distance:
-
7.5m (24.61ft) - 3840x2160@60Hz
-
15m (49.21ft) - 2560x1600@60Hz
Maximum Resolution: 3840x2160@60Hz
-
HDCP Support: 1.4
-
Transmission Medium: 2 x DisplayPort Cable
-
Special Features: DPCP Compatible
Connectors
-
Input: DisplayPort (Female)
-
Output: DisplayPort (Female)
-
Power: 3.5/1.35 DC socket
Physical Properties
-
Dimensions WxHxD: 47x31x21mm (1.85x1.22x0.83in)
-
Housing Material: Metal
-
Nett Weight: 0.07kg (0.15lb)
-
Operating Temperature: -10°C - 50°C (14°F - 122°F)
-
Storage Temperature: -20°C - 75°C (-4°F - 167°F)
-
Humidity: 10-85% RH (non-condensing)
-
Power Requirements: 5VDC 3A
-
Colour: Black
Miscellaneous
-
Packaging Type: Carton box
-
Packaging Dimensions: 185x140x55mm (7.28x5.51x2.17in)
-
Gross Weight: 0.42kg (0.93lb)
-
Warranty (Years): 2
-
Certificated: CE, FCC, RoHS & REACH
