Universaalne multimeedia konverter:
Sisend:
-
HDMI (Female)
-
Mini-DP (Female)
-
VGA (Female)
-
3.5mm (Female)
-
USB Type C (Female)
-
RJ-45 (Female)
Väljund:
-
HDMI (Female)
-
RJ-45 (Female)
Specifications
-
AV Interface: HDMI
-
Interface Standard: HDMI 2.0
-
Supports Bandwidth: 18Gbps
-
Maximum Resolution: 3840x2160@60Hz 4:4:4 8bit
-
HDCP Support: 2.2
-
Supported Audio: Audio Pass-through
-
Separate Audio Ports: Stereo (3.5mm)
-
IR Support: -
-
CEC Support: Pass-Through
-
Serial Interface: -
-
Special Features: EDID Bypass, Ethernet Pass-through
Connectors
-
Input:
-
HDMI (Female)
-
Mini-DP (Female)
-
VGA (Female)
-
3.5mm (Female)
-
USB Type C (Female)
-
RJ-45 (Female)
-
Output:
-
HDMI (Female)
-
RJ-45 (Female)
-
Control: Push Button
-
Power: 5.5/2.1mm DC socket
Physical Properties
-
Dimensions (approx.) WxDxH: 184x90x80mm (7.24x3.54x3.15in)
-
Housing Material: Metal
-
Net Weight: 0.737kg (1.62lb)
-
Operating Temperature: 0°C - 40°C (32°F - 104°F)
-
Storage Temperature: -20°C - 60°C (-4°F - 140°F)
-
Humidity: 0 – 60% RH (non-condensing)
-
Power Requirements: 5VDC 3A
-
Colour: Black
