Professionaalse valikuga DVI-D Dual Link kaabel kaubanduslikuks ja suure jõudlusega AV- ja IT-paigaldiste jaoks
Toetab DVI eraldusvõimet kuni 2560x1600 @60Hz ja HDTV eraldusvõimet kuni 1080p
Tugev PVC korpus, 24K kullatud pistikud ja kontaktid
Kolmekordselt varjestatud kaabel, korrosioonikindlad tinatud vasest 28AWG juhid
10 aastane garantii
Connectors:
-
Connector A: DVI-D Male (Dual Link)
-
Connector B: DVI-D Male (Dual Link)
-
Housing Material: PVC
-
Connector Plating: 24K Gold 1µm
-
Pin Construction: Brass
-
Pin Plating: 24K Gold 1µm
-
Dimensions (approx.) WxDxH: 39.5x16.5x44.5mm (1.56x0.65x1.75in)
Cable Construction:
-
Length: 0.5m (1.64ft)
-
Standard: DVI-D Dual Link
-
Colour: Black
-
Type: Round
-
Jacket Diameter: 8.6mm (0.34in)
-
Jacket Material: PVC
-
Conductor Material: Tinned Copper
-
Conductor Gauge: 28AWG
-
Shielding: Copper Braid 85%
Specifications:
-
Supported Bandwidth: 9.9 Gbps
-
Maximum Resolution: 2560x1600@60Hz
-
Nominal Attenuation: 1 - 825Mhz < 8db
-
Minimum Bend Radius: 86mm (3.39in)
-
Operating Temperature: -20°C - 80°C (-4°F - 176°F)
-
Storage Temperature: -25°C - 85°C (-13°F - 185°F)
Miscellaneous:
-
Packaging Type: Polybag
-
Warranty (Years): 10
-
Certificated: RoHS, REACH, UL
