Specification
AV Interface: HDMI
Interface Standard: 2.0
Supported Bandwidth: 18 Gbps
Maximum Resolution: 3840x2160@60Hz 4:4:4 8Bit / 4:2:2 12Bit
Video EDID:
640 x 480p at 60Hz , 640 x 480p at 67Hz , 640 x 480p at 72Hz , 640 x 480p at 75Hz
720 x 480p at 60Hz ,
720 x 480i at 60Hz ,
720 x 400p at 70Hz ,
720 x 576p at 60Hz
720 x 576i at 50Hz
800 x 600p at 56Hz , 800 x 600p at 60Hz , 800 x 600p at 72Hz , 800 x 600p at 75Hz
832 x 624p at 75Hz ,
1024 x 768p at 60Hz , 1024 x 768p at 70Hz , 1024 x 768p at 75Hz
1280 x 1024p at 75Hz ,
1280 x 720p at 50Hz
1152 x 870p at 75Hz ,
1152 x 864p at 75Hz
1280 x 1024p at 60Hz ,
1280 x 960p at 60Hz
1440 x 480p at 60Hz ,
1440 x 576p at 50Hz ,
1440 x 900p at 60Hz
1600 x 1200p at 60Hz
1680 x 1050p at 60Hz
1920 x 1080p at 60Hz , 1920 x 1080p at 50Hz ,
1920 x 1080i at 60Hz , 1920 x 1080i at 50Hz
1920 x 1200p at 60Hz ,
2560 x 1440p at 60Hz
3840 x 2160p at 24Hz , 3840 x 2160p at 30Hz , 3840 x 2160p at 60Hz
Audio EDID: LPCM 2-channel, 16/20/24 bit depths at 32/44/48/88/96/176/192 kHz
HDCP Support: 2.2
Special Features: High Dynamic Range Support, CEC Compatible
Connectors
-
Input: HDMI Type A Male
-
Output: HDMI Type A Female
-
Power: Via HDMI Source Interface
Physical Properties
-
Dimensions WxDxH: 24x34.3x11.8mm (0.94x1.35x0.46in)
-
Housing Material: ABS
-
Net Weight: 0.008kg (0.02lb)
-
Operating Temperature: 0°C - 60°C (32°F - 140°F)
-
Storage Temperature: -10°C - 70°C (14°F - 158°F)
-
Humidity: 0 - 80% RH (non-condensing)
-
Power Requirements: -
-
Colour: Black
