Specifications
-
AV Interface: HDMI
-
Interface Standard: HDMI 2.0
-
Supported Bandwidth: 18Gbps
-
Maximum Resolution: 3840x2160@60Hz 4:4:4 8Bit / 4:2:2 12Bit
-
Video EDID
Audio EDID: LPCM 2-channel, 16/20/24 bit depths at 32/44/48/88/96/176/192 kHz
HDCP Support: 2.2
Special Features: High Dynamic Range Support, CEC Compatible
Connectors
-
Input: HDMI Type A Male
-
Output: HDMI Type A Female
-
Power: Via HDMI Source Interface
Physical Properties
-
Dimensions (approx.) WxDxH: 24x43x12.3mm (0.94x1.69x0.48in)
-
Housing Material: ABS
-
Net Weight: 0.008kg (0.02lb)
-
Operating Temperature: 0°C - 60°C (32°F - 140°F)
-
Storage Temperature: -10°C - 70°C (14°F - 158°F)
-
Humidity: 0 - 80% RH (non-condensing)
-
Power Requirements: -
-
Colour: Black
Miscellaneous
-
Packaging Type: Polybag
-
Packaging Dimensions: 136x138mm (5.35x5.43in)
-
Gross Weight: 0.013kg (0.03lb)
-
Warranty (Years): 2
-
Certificated: CE, FCC, RoHS & REACH
Package Contents
-
HDMI 2.0 EDID Emulator
-
Lindy Manual
Purchasing Information
-
No.32104
-
EAN: 4002888321044
